Coating Production Line Electrostatic Optiflex 2 B Powder Coating Paint Spray Machine
Coating Production Line Electrostatic Optiflex 2 B Powder Coating Paint Spray Machine
Coating Production Line Electrostatic Optiflex 2 B Powder Coating Paint Spray Machine
Coating Production Line Electrostatic Optiflex 2 B Powder Coating Paint Spray Machine
Coating Production Line Electrostatic Optiflex 2 B Powder Coating Paint Spray Machine
Coating Production Line Electrostatic Optiflex 2 B Powder Coating Paint Spray Machine
Coating Production Line Electrostatic Optiflex 2 B Powder Coating Paint Spray Machine
Coating Production Line Electrostatic Optiflex 2 B Powder Coating Paint Spray Machine
Specifications
Place of Origin :
zhejiang
Brand Name :
huaxiang
Price :
$1,071.00/pieces 1-20 pieces
MOQ :
1
Type :
Coating Production Line
Substrate :
Steel
Condition :
New
Machine Type :
powder coating machine, Coating Equipment
Video outgoing-inspection :
Provided
Machinery Test Report :
Provided
Marketing Type :
Ordinary Product
Warranty of core components :
1 Year
Core Components :
PLC
Coating :
Painting
Voltage :
380V/220V/110V
Power :
50kw
Dimension(L*W*H) :
95cm*43cm*107cm
Warranty :
1 Year
Key Selling Points :
Easy to Operate
Applicable Industries :
Building Material Shops, Machinery Repair Shops, Manufacturing Plant
Showroom Location :
None
Weight (KG) :
33
Product name :
Paint Coating System
Usage :
Powder Coating Workpieces
Color :
Customized Colors
Description

vHXC ibration-type electrostatic powder coating machine is a specialized device designed to enhance the efficiency and uniformity of powder coating application. This machine utilizes a vibration mechanism to improve the flow and distribution of powder particles, allowing for better coating coverage on various surfaces.

  1. Vibration Mechanism: The machine incorporates a vibration system that helps to keep the powder in a fluidized state, preventing clumping and ensuring consistent flow to the spray gun.

  2. Electrostatic Charging: Similar to standard electrostatic powder coating machines, this type uses high voltage to charge the powder particles, enhancing their adhesion to the grounded workpiece.

  3. Adjustable Parameters: Users can typically adjust settings such as vibration intensity, powder feed rate, and spraying distance for optimal performance.

  4. Compact Design: Many models are designed to occupy less space, making them suitable for small workshops or laboratories.

Working Principle

  1. Powder Fluidization: The vibration mechanism keeps the powder particles agitated and evenly distributed, facilitating a smooth flow.

  2. Charging and Spraying: As the powder moves to the spray gun, it is charged electrostatically. The charged particles are then sprayed onto the workpiece, which is usually grounded to attract the powder.

  3. Curing: After application, the coated workpiece is placed in a curing oven where heat is applied to melt and solidify the powder, forming a durable coating.

Coating Production Line Electrostatic Optiflex 2 B Powder Coating Paint Spray Machine
Electrostatic Optiflex 2 B Powder Coating Paint Spray Machine
Item
Deta
Voltage
110v/220v
Frenquency
50/60HZ
Input power
50W
Max. output current
200ua
Output power voltage
0-100kv
Input Air pressure
0.3-0.6Mpa
Powder consumption
Max 550g/min
Length of Gun Cable
5 m
Gun weight
480g
