Canned Baby Food Small Retort Machine Canning Sterilizer
Canned Baby Food Small Retort Machine Canning Sterilizer
Canned Baby Food Small Retort Machine Canning Sterilizer
Canned Baby Food Small Retort Machine Canning Sterilizer
Specifications
MOQ :
1set
Price :
USD 11500 PER SET
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
11 SETS PER MONTH
Delivery Time :
20-25 WORKING DAYS
Packaging Details :
film cover and then loaded to the container
Product Name :
Small Canned Baby Food Retort Pouch Sterilization Machine
Key Selling Point :
Energy saving
Keywords :
Food Sterilizer Machine
Application :
food product sterilization
Sterilizing way :
water immersion
Advantage :
Low consumption
Machine Test :
provided
Warranty :
1 year
Material :
SUS304
Function :
High temperature high pressure sterilization
Description

Small Canned Baby Food Retort Pouch Sterilization Machine

retortas sterilizer machine Scope of application

For all heat resistant and waterproof package material
1. Glass container: Glass bottle, glass jar
2. Mental can: tin can.tin canned, aluminum can
3. Plastic container serial: PP bottles
4. Flexible pouch serial: flexible retort pouch laminated film bag, high temperature cooking bag, vacuum bag

Ltem Unit
1000#
1200#
1300#
Kettle Length(mm)
2400
2400
3200
3600
4000
3600
4500
Total Length(mm)
3900
4400
5200
5600
6000
5800
6700
Total Width(mm)
1400
1600
1600
1600
1600
1800
1800
Total Height(mm)
3200
3500
3500
3500
3500
3800
3800
Total Capacity m3
2.2
3.2
4
4.6
4.9
5.3
6.5
Food Basket (unit)
3
3
4
4
5
4
5
Gas Consumption KG/batach
115
180
230
255
280
300
370
Total Efficiency (KW)
8
14
14
14
14
21.5
21.5
Energy Cost KW/h
5
8
8
8
8
8
8
Designed Temperature (C)
145
Test Pressure
0.44Mpa
Designed Pressure
0.35Mpa

Canned Baby Food Small Retort Machine Canning Sterilizer

retortas sterilizer machine Application Principle

1. atomized germicidal water can expand heat exchange area and realize high efficiency heat exchange mode
2. steam and atomized sterilizing water are directly exchanged in sterilizing kettle. Steam heat 100% use, zero energy loss,maximum energy efficiency
3. a small amount of sterilizing water circulation quickly, the water temperature is uniform and rapid heating up to the set
working temperature
4. nozzles are sprayed from different angles to create a high heat flow in the sterilizer, thus evenly distributing the
temperature in the pot
5. the sterilization effect (F value) is set in advance to control the whole sterilization process, so that the sterilization
effect becomes intuitive, controllable, and ensures that the sterilization effect of each sterilization batch is consistent, and
is no longer affected by the heating rate and product volume. It is of great practical significance for canned food processing
enterprises to realize the standardized production of "commercial aseptic" food
Canned Baby Food Small Retort Machine Canning Sterilizer

retortas sterilizer machine Advantage

1. No exhaust, low noise, 18% steam energy saving (compared with water immersion and steam sterilizer).
2. Direct heating and cooling without heat exchanger to improve heating and cooling speed.
3. Adjust the sterilization temperature arbitrarily and calculate the sterilization temperature automatically.
4. The kettle is equipped with four movable temperature probes, which can monitor the F value of the food center and observe the heat distribution in the kettle at any time.
Canned Baby Food Small Retort Machine Canning Sterilizer
