Oil Quantity 2.8L 18kw Open Frame Gasoline Generator 75 DBA/7m
Oil Quantity 2.8L 18kw Open Frame Gasoline Generator 75 DBA/7m
Oil Quantity 2.8L 18kw Open Frame Gasoline Generator 75 DBA/7m
Oil Quantity 2.8L 18kw Open Frame Gasoline Generator 75 DBA/7m
Oil Quantity 2.8L 18kw Open Frame Gasoline Generator 75 DBA/7m
Oil Quantity 2.8L 18kw Open Frame Gasoline Generator 75 DBA/7m
Oil Quantity 2.8L 18kw Open Frame Gasoline Generator 75 DBA/7m
Oil Quantity 2.8L 18kw Open Frame Gasoline Generator 75 DBA/7m
Oil Quantity 2.8L 18kw Open Frame Gasoline Generator 75 DBA/7m
Oil Quantity 2.8L 18kw Open Frame Gasoline Generator 75 DBA/7m
Oil Quantity 2.8L 18kw Open Frame Gasoline Generator 75 DBA/7m
Oil Quantity 2.8L 18kw Open Frame Gasoline Generator 75 DBA/7m
Specifications
Brand Name :
HUAN NENG
Model Number :
GG25000LE
Certification :
CE, ISO 14001, ISO 9001
Place of Origin :
Chongqing, China
MOQ :
1 Set
Price :
Negotiable
Payment Terms :
T/T, L/C, Western Union, MoneyGram
Supply Ability :
20000 sets per month
Delivery Time :
7-15 work days
Packaging Details :
Carton box packing for each set
weight :
200kg
Package :
Wooden pallet + hard carton
Dimensions :
1050*670*750
Continuous working time :
8h
noise :
75dBA/7m
Caster attachment :
Standard
control panel :
digital display
fuel indicator :
Have
battery capacity :
12V-36AH maintenance-free battery
easy fuel :
30L
Start method :
Electric start
oil quantity :
2.8L
Description

18kw Rated 20kw High-Power Twin-Cylinder Four-Stroke, Air-Cooled, Overhead Valve Open Frame Gasoline Generator

18kw Gasoline Generator

THE BENEFIT:

- Powerful commercial grade V-twin engine, low vibration, low emission, more durable, more stable, more reliable and more powerful.
- Precisely controlled ignition, intelligent speed control according to the load, saving fuel not only a little, economic and efficient both.
- Short-circuit protection more to the home, safe and reliable more effective.
- Humanized design concept, integrated panel operation, clearly visible and easy to operate.
- Carefully designed commercial high-power generator, covering 110-415V, single/three-phase, minimizing maintenance and servicing costs.
- Fitted with safety protection system and large oil tank to ensure long time operation, 7 hours continuous operation at rated power.
- Oil protection system, oil low oil level automatic alarm stop, prevent the engine from working under low oil level, give more protection to the engine.
- Omni-directional moving wheels, towing, pulling and turning in one go, easy to achieve. -Prepared ATS fully automatic terminal, power failure can be automatically started under unattended condition"

ADD: if you want to know more details, please contact us.

THE DETAILS

The unit type BL18000W BL25000W BL31000W BL36000W
Generator Rated speed 15KW 18KW 23kw 28kw
Rated frequency 50hz 50hz 50hz 50hz
The rated voltage 230V/400V 230V/400V 230V/400V 230V/400V
Power factor 1.0/0.8 1.0/0.8 1.0/0.8 1.0/0.8
Phase velocity 1 phase 2 lines /3 phase 4 lines 1 phase 2 lines /3 phase 4 lines 1 phase 2 lines /3 phase 4 lines 1 phase 2 lines /3 phase 4 lines
Excitation way Brushless self-propelled magnetic Brushless self-propelled magnetic Brushless self-propelled magnetic Brushless self-propelled magnetic
Insulation class H H H H
Protection grade IP23 IP23 IP23 IP23
engine model Inline four-cylinder four-stroke EFI water-cooled electronically controlled gasoline injection
One hour power none data none data none data none data
Rated speed 1500r/min 1500r/min 1500r/min 1500r/min
Start the way electric start electric start electric start electric start
In the form of Straight line, straight spray Straight line, straight spray Straight line, straight spray Straight line, straight spray
Air inlet Naturally aspirated Naturally aspirated Naturally aspirated Naturally aspirated
stroke 4 4 4 4
Number of cylinders 4 4 4 4
Cylinder diameter, stroke 65x78mm 65x78mm 70x79mm 70x79mm
Speed way mechanical mechanical mechanical mechanical
Stop the direction mechanical mechanical mechanical mechanical
The crankshaft to counterclockwise counterclockwise counterclockwise counterclockwise
The oil brand CD15/40GB11122 CD15/40GB11122 CD15/40GB11122 CD15/40GB11122
Fuel consumption rate 200 g/kw or less. H 200 g/kw or less. H 200 g/kw or less. H 200 g/kw or less. H
Oil consumption rate 1.5 g/kw or less. H 1.5 g/kw or less. H 1.5 g/kw or less. H 1.5 g/kw or less. H

Generator sets		 Rated power 15kw 18kw 23kw 28kw
The rated voltage 230V/400V 230V/400V 230V/400V 230V/400V
Maximum current 69.5 A/each phase 21.7 A 78 A/each phase 26 A 100 A/each phase 33.3 A each phase 40.5 A
Rated frequency 50hz 50hz 50hz 50hz
Power factor 1.0/0.8 1.0/0.8 1.0/0.8 1.0/0.8
Cooling way Closed fan water cooled Closed fan water cooled Closed fan water cooled Closed fan water cooled
Fuel tank capacity 25L 25L 35L 35L
The noise 72Dba/7m 72Dba/7m 72Dba/7m 72Dba/7m
The weight of the 282kg 298kg 324kg 324kg
Overall dimensions 1130x720x800mm 1130x720x800mm 1300x820x800mm 1300x820x800mm
