Smartgen Deepsea Silent Gasoline Generator 20kw Silent Diesel Generator
Smartgen Deepsea Silent Gasoline Generator 20kw Silent Diesel Generator
Smartgen Deepsea Silent Gasoline Generator 20kw Silent Diesel Generator
Smartgen Deepsea Silent Gasoline Generator 20kw Silent Diesel Generator
Smartgen Deepsea Silent Gasoline Generator 20kw Silent Diesel Generator
Smartgen Deepsea Silent Gasoline Generator 20kw Silent Diesel Generator
Smartgen Deepsea Silent Gasoline Generator 20kw Silent Diesel Generator
Smartgen Deepsea Silent Gasoline Generator 20kw Silent Diesel Generator
Specifications
Brand Name :
HUAN NENG
Model Number :
BL25000W
Certification :
CE, ISO 14001, ISO 9001
Place of Origin :
Chongqing, China
MOQ :
1 Set
Price :
Negotiable
Payment Terms :
T/T, L/C, Western Union, MoneyGram
Supply Ability :
20000 sets per month
Delivery Time :
7-15 work days
Packaging Details :
Carton box packing for each set
Rated power :
18KW
Controller :
Smartgen/Deepsea
Options :
Silent/ATS/controller
Generator type :
Silence Generator Set
feature :
Patent technology
Warranty :
12 Months,1 Year,One year warranty
Description

Rated 18000W Max 20KW Complete qualification certificate gasoline silent generator

Maximum 20KW Silent Gasoline Generator

THE ADVANTAGE OF OUR PRODUCTS :

We 100% test the product before it is packed. Our products have CE, GS, ROHS, ISO9001, TUV, SONCAP certificates. It comes with a 12-month warranty to ensure the longevity of the product. The waveform is good and the frequency is stable. Suitable for air conditioners, angle grinders, impact drills, electric drills, electric furnaces, communication equipment, lighting, etc.You are worth to have it.

The Details

The unit type BL18000W BL25000W BL31000W BL36000W
Generator Rated speed 15KW 18KW 23kw 28kw
Rated frequency 50hz 50hz 50hz 50hz
The rated voltage 230V/400V 230V/400V 230V/400V 230V/400V
Power factor 1.0/0.8 1.0/0.8 1.0/0.8 1.0/0.8
Phase velocity 1 phase 2 lines /3 phase 4 lines 1 phase 2 lines /3 phase 4 lines 1 phase 2 lines /3 phase 4 lines 1 phase 2 lines /3 phase 4 lines
Excitation way Brushless self-propelled magnetic Brushless self-propelled magnetic Brushless self-propelled magnetic Brushless self-propelled magnetic
Insulation class H H H H
Protection grade IP23 IP23 IP23 IP23
engine model Inline four-cylinder four-stroke EFI water-cooled electronically controlled gasoline injection
One hour power none data none data none data none data
Rated speed 1500r/min 1500r/min 1500r/min 1500r/min
Start the way electric start electric start electric start electric start
In the form of Straight line, straight spray Straight line, straight spray Straight line, straight spray Straight line, straight spray
Air inlet Naturally aspirated Naturally aspirated Naturally aspirated Naturally aspirated
stroke 4 4 4 4
Number of cylinders 4 4 4 4
Cylinder diameter, stroke 65x78mm 65x78mm 70x79mm 70x79mm
Speed way mechanical mechanical mechanical mechanical
Stop the direction mechanical mechanical mechanical mechanical
The crankshaft to counterclockwise counterclockwise counterclockwise counterclockwise
The oil brand CD15/40GB11122 CD15/40GB11122 CD15/40GB11122 CD15/40GB11122
Fuel consumption rate 200 g/kw or less. H 200 g/kw or less. H 200 g/kw or less. H 200 g/kw or less. H
Oil consumption rate 1.5 g/kw or less. H 1.5 g/kw or less. H 1.5 g/kw or less. H 1.5 g/kw or less. H

Generator sets		 Rated power 15kw 18kw 23kw 28kw
The rated voltage 230V/400V 230V/400V 230V/400V 230V/400V
Maximum current 69.5 A/each phase 21.7 A 78 A/each phase 26 A 100 A/each phase 33.3 A each phase 40.5 A
Rated frequency 50hz 50hz 50hz 50hz
Power factor 1.0/0.8 1.0/0.8 1.0/0.8 1.0/0.8
Cooling way Closed fan water cooled Closed fan water cooled Closed fan water cooled Closed fan water cooled
Fuel tank capacity 25L 25L 35L 35L
The noise 72Dba/7m 72Dba/7m 72Dba/7m 72Dba/7m
The weight of the 282kg 298kg 324kg 324kg
Overall dimensions 1130x720x800mm 1130x720x800mm 1300x820x800mm 1300x820x800mm
