6KW One Cylinder Open Frame Three Phase Gasoline Generator 190F
6KW One Cylinder Open Frame Three Phase Gasoline Generator 190F
6KW One Cylinder Open Frame Three Phase Gasoline Generator 190F
6KW One Cylinder Open Frame Three Phase Gasoline Generator 190F
6KW One Cylinder Open Frame Three Phase Gasoline Generator 190F
6KW One Cylinder Open Frame Three Phase Gasoline Generator 190F
6KW One Cylinder Open Frame Three Phase Gasoline Generator 190F
6KW One Cylinder Open Frame Three Phase Gasoline Generator 190F
6KW One Cylinder Open Frame Three Phase Gasoline Generator 190F
6KW One Cylinder Open Frame Three Phase Gasoline Generator 190F
Specifications
Brand Name :
HUAN NENG
Model Number :
YD7600S/SD
Certification :
CE, ISO 14001, ISO 9001
Place of Origin :
Chongqing, China
MOQ :
1 Set
Price :
Negotiable
Payment Terms :
T/T, L/C, Western Union, MoneyGram
Supply Ability :
20000 sets per month
Delivery Time :
7-15 work days
Packaging Details :
Carton box packing for each set
Product name :
Silent Gasoline Generator
Warranty :
dpends on products
Engine :
China Engine （192）
Color :
Customized according to customer
phase :
Three-Phases
Cooling method :
air cool
Description

6KW One Cylinder 3 Phases Open-Frame Hand/Electric Start Gasoline Generator

Three-Phases ​ 6KW Gasoline Generator
THE ADVANTAGE :
1. Focus on quality, service and reliability and listen to customers
2. Combining modern technology, quality and aesthetics
3. Continuously improve productivity and review existing workflows

ADD: if you want to know more details, please contact us.

Unit TypeYD6600EYD7600EYD10000E
Excitation methodAVRAVRAVR
maximum output power6.0KW7.0KW8.5KW
Rated output power5.0KW6.5KW8.0KW
Rated voltage230/400V230/400V230/400V
Maximum current26.0A30.4A37.0A
Rated frequency50hz50hz50hz
Phasesingle phase/three phasesingle phase/three phasesingle phase/three phase
power factor cose1.0/0.81.0/0.81.0/0.8
Insulation classFFF
Guide model190F190F190F
Bore X Stroke90x66mm90x66mm90x66mm
Displacement420cc420cc420cc
fuel consumption rateW374g/KW.hW374g/KW.hW374g/KW.h
ignition methodtransistor electronic ignitiontransistor electronic ignitiontransistor electronic ignition
engine typeSingle cylinder, four stroke, forced air cooling, overhead valveSingle cylinder, four stroke, forced air cooling, overhead valveSingle cylinder, four stroke, forced air cooling, overhead valve
fuel type90# or more gasoline90# or more gasoline90# or more gasoline
oil quantity1.1L1.1L1.1L
Start methodHand start/electric startHand start/electric startHand start/electric start
fuel capacity20L20L20L
oil alarmHaveHaveHave
fuel indicatorHaveHaveHave
control panelotherotherother
Caster attachmentStandardStandardStandard
noise68Dba/7m68Dba/7m68Dba/7m
Continuous working time8h8h8h
Unit size1050x590x800mm1050x590x800mm1050x590x800mm
weight145kg148kg156kg

6KW One Cylinder Open Frame Three Phase Gasoline Generator 190F6KW One Cylinder Open Frame Three Phase Gasoline Generator 190F6KW One Cylinder Open Frame Three Phase Gasoline Generator 190F
6KW One Cylinder Open Frame Three Phase Gasoline Generator 190F6KW One Cylinder Open Frame Three Phase Gasoline Generator 190F6KW One Cylinder Open Frame Three Phase Gasoline Generator 190F6KW One Cylinder Open Frame Three Phase Gasoline Generator 190F6KW One Cylinder Open Frame Three Phase Gasoline Generator 190F6KW One Cylinder Open Frame Three Phase Gasoline Generator 190F
