Open FrameThree Phases ​Silent Gasoline Generator 5kw 420cc
Open FrameThree Phases ​Silent Gasoline Generator 5kw 420cc
Open FrameThree Phases ​Silent Gasoline Generator 5kw 420cc
Open FrameThree Phases ​Silent Gasoline Generator 5kw 420cc
Open FrameThree Phases ​Silent Gasoline Generator 5kw 420cc
Open FrameThree Phases ​Silent Gasoline Generator 5kw 420cc
Open FrameThree Phases ​Silent Gasoline Generator 5kw 420cc
Open FrameThree Phases ​Silent Gasoline Generator 5kw 420cc
Specifications
Brand Name :
HUAN NENG
Model Number :
YD6600S/SD
Certification :
CE, ISO 14001, ISO 9001
Place of Origin :
Chongqing, China
MOQ :
1 Set
Price :
Negotiable
Payment Terms :
T/T, L/C, Western Union, MoneyGram
Supply Ability :
20000 sets per month
Delivery Time :
7-15 work days
Packaging Details :
Carton box packing for each set
Product name :
Totally Silent Gasoline Generator
Feature :
Compact body
Function :
Heavy Generator Provide Electric Power
Type :
Open Frame,Open Frame / Silent Type / Trailer / Auto Station / Contanerzied
Alternator type :
Brush alternator with AVR or brushless with AVR
Oem :
Available
Description

5KW Strong Continuity High Stability Easy To Maintain Gasoline Generator

Three-Phases ​ 5KW Gasoline Generator
THE ADVANTAGE :
We test 100% of our products before they are packaged. Our products . Have CE, GS, ROHS, ISO9001, TUV, SONCAP certification. We have 12 months warranty, which will guarantee the long life of the product. Good waveform and stable frequency. Suitable for air conditioner, angle grinder, impact drill, electric drill, electric furnace, communication equipment and lighting etc.

ADD: if you want to know more details, please contact us.

Unit TypeYD6600EYD7600EYD10000E
Excitation methodAVRAVRAVR
maximum output power6.0KW7.0KW8.5KW
Rated output power5.0KW6.5KW8.0KW
Rated voltage230/400V230/400V230/400V
Maximum current26.0A30.4A37.0A
Rated frequency50hz50hz50hz
Phasesingle phase/three phasesingle phase/three phasesingle phase/three phase
power factor cose1.0/0.81.0/0.81.0/0.8
Insulation classFFF
Guide model190F190F190F
Bore X Stroke90x66mm90x66mm90x66mm
Displacement420cc420cc420cc
fuel consumption rateW374g/KW.hW374g/KW.hW374g/KW.h
ignition methodtransistor electronic ignitiontransistor electronic ignitiontransistor electronic ignition
engine typeSingle cylinder, four stroke, forced air cooling, overhead valveSingle cylinder, four stroke, forced air cooling, overhead valveSingle cylinder, four stroke, forced air cooling, overhead valve
fuel type90# or more gasoline90# or more gasoline90# or more gasoline
oil quantity1.1L1.1L1.1L
Start methodHand start/electric startHand start/electric startHand start/electric start
fuel capacity20L20L20L
oil alarmHaveHaveHave
fuel indicatorHaveHaveHave
control panelotherotherother
Caster attachmentStandardStandardStandard
noise68Dba/7m68Dba/7m68Dba/7m
Continuous working time8h8h8h
Unit size1050x590x800mm1050x590x800mm1050x590x800mm
weight145kg148kg156kg

Open FrameThree Phases ​Silent Gasoline Generator 5kw 420ccOpen FrameThree Phases ​Silent Gasoline Generator 5kw 420ccOpen FrameThree Phases ​Silent Gasoline Generator 5kw 420cc
Open FrameThree Phases ​Silent Gasoline Generator 5kw 420ccOpen FrameThree Phases ​Silent Gasoline Generator 5kw 420ccOpen FrameThree Phases ​Silent Gasoline Generator 5kw 420ccOpen FrameThree Phases ​Silent Gasoline Generator 5kw 420ccOpen FrameThree Phases ​Silent Gasoline Generator 5kw 420ccOpen FrameThree Phases ​Silent Gasoline Generator 5kw 420cc
