1090mm - 1360mm Detecting Pole Length Mine Detector Waterproof
1090mm - 1360mm Detecting Pole Length Mine Detector Waterproof
1090mm - 1360mm Detecting Pole Length Mine Detector Waterproof
1090mm - 1360mm Detecting Pole Length Mine Detector Waterproof
1090mm - 1360mm Detecting Pole Length Mine Detector Waterproof
1090mm - 1360mm Detecting Pole Length Mine Detector Waterproof
Specifications
Brand Name :
HEWEI
Model Number :
UMD-III
Certification :
YES
Place of Origin :
China
MOQ :
1 set
Price :
USD 1600~2500
Payment Terms :
T/T
Supply Ability :
100 sets per month
Delivery Time :
15 ~30 working days
Packaging Details :
carton package, wooden package.
Name :
1090mm～1360mm detecting pole length Mine detector
Weight :
3 kg
Transport weight :
12.3 kg
The detecting pole length :
1090mm～1360mm
Battery :
LR20 Manganese alkali dry cell
Battery life :
At maximum sensitivity - 12 hours At medium and low sensitivity - 18 hours Low voltage alarming by sound and light
Detection sensitivity :
Detection sensitivity
Operating humidity :
Fully enclosed and be able to operate 2 m under water.
Description

1090mm～1360mm detecting pole length, water-prooof Mine detector

Mine detector

Description

UMD-III mine detector is a widely used hand-held (single-soldier operating) mine detector. It adopts high frequency pulse induction technology and it is highly sensitive, especially suitable for detecting minor metal mines. The operation is simple, so the operators can use the device only after a short training.

Features

  • Waterproof, which can be detected under water.
  • Being controlled by a microprocessor with accurate timing, fast conversion and strong signal processing capability.
  • Super sensitivity to identify very small metal objects.

1090mm - 1360mm Detecting Pole Length Mine Detector Waterproof

Technical Parameters

Weight 3kg
Transport weight 12.3 kg
The detecting pole length 1090mm～1360mm
Battery LR20 Manganese alkali dry cell
Battery life

At maximum sensitivity - 12 hours

At medium and low sensitivity - 18 hours

Low voltage alarming by sound and light
Detection sensitivity 0.05gr Stainless steel at 75mm distance from the probe
Operating humidity Fully enclosed and be able to operate 2 m under water.
Operating temperature -25°C～70°C
Storage temperature -25°C～70°C
The detecting coil The longest detecting pole is 1120mm, the shortest is 700mm, and weight 1100g. Glass resin telescopic rod, the surface is coated to protect the environment.The diameter of detecting coil is 300mm, black ABS material, surface is treated with EMC, and a hybrid RX coil is used to improve the signal/noise ratio.

Company Introduction

In 2008, Beijing Hewei Yongtai Technology Co., LTD was established in Beijing.Focus on the development and operation of special safety equipment, mainly serve the public security law, armed police, military, customs and other national security departments.

In 2010, Jiangsu Hewei Police Equipment Manufacturing Co., LTD was established in Guannan.Covering an area of 9000 square meters of workshop and office building, it aims to build a first-class special safety equipment research and development base in China.

In 2015, a military-police Reserch and development center was set up in Shenzhen.Focus on the development of special safety equipment, has developed more than 200 kinds of professional safety equipment.

Jiangsu Factory

1090mm - 1360mm Detecting Pole Length Mine Detector Waterproof

1090mm - 1360mm Detecting Pole Length Mine Detector Waterproof

Shenzhen Research Centre

1090mm - 1360mm Detecting Pole Length Mine Detector Waterproof

1090mm - 1360mm Detecting Pole Length Mine Detector Waterproof


Overseas Exhibitions

1090mm - 1360mm Detecting Pole Length Mine Detector Waterproof

1090mm - 1360mm Detecting Pole Length Mine Detector Waterproof




Certificates

1090mm - 1360mm Detecting Pole Length Mine Detector Waterproof

1090mm - 1360mm Detecting Pole Length Mine Detector Waterproof

1090mm - 1360mm Detecting Pole Length Mine Detector Waterproof



Staff Photo

Staff from Jiangsu Factory
1090mm - 1360mm Detecting Pole Length Mine Detector Waterproof

Staff from Headquarters

1090mm - 1360mm Detecting Pole Length Mine Detector Waterproof

Staff from Shenzhen research centre

1090mm - 1360mm Detecting Pole Length Mine Detector Waterproof
