50 - 60kv Electric Shock Gun For Safety Constant 20pps Pure Dc Damping Pulse
50 - 60kv Electric Shock Gun For Safety Constant 20pps Pure Dc Damping Pulse
50 - 60kv Electric Shock Gun For Safety Constant 20pps Pure Dc Damping Pulse
50 - 60kv Electric Shock Gun For Safety Constant 20pps Pure Dc Damping Pulse
50 - 60kv Electric Shock Gun For Safety Constant 20pps Pure Dc Damping Pulse
50 - 60kv Electric Shock Gun For Safety Constant 20pps Pure Dc Damping Pulse
50 - 60kv Electric Shock Gun For Safety Constant 20pps Pure Dc Damping Pulse
50 - 60kv Electric Shock Gun For Safety Constant 20pps Pure Dc Damping Pulse
Specifications
Brand Name :
HEWEI
Model Number :
HW-SG6
Certification :
CE,ROHS,ISO,etc
Place of Origin :
Made-in-China
MOQ :
1 Set
Price :
USD per piece FOB Beijing
Payment Terms :
T/T
Supply Ability :
300 pieces per month
Delivery Time :
15 working days
Packaging Details :
Length 190 mm Height 68 mm Width 39 mm
Pulse shape :
Pure DC damping pulse
Voltage output :
50-60KV
Pulse duration :
80-120μs
Battery :
3 x 3V Lithium battery
Pulse frequency :
Constant 20PPS
Current :
1.6-1.8mA/Second
Cloth penetration :
Accumulated 5 cm
Discharge time :
5 Seconds
Laser sight :
650, 635nm
Case :
High-impact polymeric plastic
Description

Electrical Shock Gun

50 - 60kv Electric Shock Gun For Safety Constant 20pps Pure Dc Damping Pulse

The world’s most safe electrical shock gun!

The longest shooting range!

The highest accuracy!

Product Structure Diagram

More features to increase value

1. whole "anti-water" function: The entire device (including cartridge and battery) works properly after being merged under water for many hours. Under-water operation is also possible without the user being electrically shocked.

2. Same type cartridge for targets at all range: reversible cartridge installation, no specific installation orientation needed.

3. Cartridge quick-release mechanism: The cartridge can be quickly released with the same operating hand after use, greatly shortening the time for reloading.

4. Integrated safe/power switch & battery locking mechanism: effectively avoids accidental power-on and loss of power during daily use.

Product Specification

Main Unit
Pulse shape Basic feature Pure DC damping pulse
Voltage output Peak discharge voltage 50-60KV
Pulse duration Single pulse 80-120μs
Battery 9V 3 x 3V Lithium battery
Pulse frequency Frequency/Second Constant 20PPS
Current Pure DC/Average value 1.6-1.8mA/Second
Cloth penetration Thickness Accumulated 5 cm
Discharge time Automatic 5 Seconds
Laser sight Wave length 650, 635nm
Case Material High-impact polymeric plastic

Dimension/weigh

 Length 178 mm
Height 128 mm
Width 31 mm
Weigh 280 g
Relevant Patents: 200610005042.X,201520504010.9；201520925906.4；201210387092.4；201521036201.3；201520925906.4
Cartridge
Case Material High-impact polymeric plastic

Dimension/weigh

 Length 50 mm
Height 32 mm
Width 29 mm
Weigh 75 g
Relevant Patents: 201520049873.1；201520049838.X； 201510035966.3；20170913829.X; 201510035966.3； 201621212942.7
Anti-rob Quick-release Holster
Case Material High-impact polymeric plastic

Dimension/weigh

 Length 190 mm
Height 68 mm
Width 39 mm
Weigh 160 g
