Oil Free Gas Vortex Blower Fan 30kPa Vacuum aluminum High Pressure Ring Blower

Specifications

Brand Name :

Popula

Motorpower :

0.5 kW - 30 kW

Type :

Centrifugal

Place of Origin :

China

Operatingtemperature :

-20°C to 80°C

Productname :

Industrial Centrifugal Fan

Speed :

500 - 3600 RPM

Noiselevel :

65 - 85 dB

Pressurerange :

500 - 5000 Pa

Mountingtype :

Horizontal / Vertical

Supply Ability :

100000 Sets/week

Outletdiameter :

150 - 1000 mm

Application :

Ventilation, Dust Collection, Material Handling

Airflowcapacity :

1000 - 50000 CFM

Certification :

CE, UL, Rohs

MOQ :

1 set

Payment Terms :

T/T

Material :

Steel / Stainless Steel

Delivery Time :

2 two days for sampe order and 10 days for bulk order

Powersupply :

220V / 380V / 440V

Protectionclass :

IP54 / IP55

Inletdiameter :

200 - 1200 mm

Description

PXG POPULA High Performance Ring

Name: Oil Free Gas Vortex Blower Fan 30kPa Vacuum aluminum High Pressure Ring Blower
Brand: Popula
Price: 1 USD

* Model PXG-0.18 ~ PXG-7.5 of POPULA PXG vortex blower consists of die-cast aluminum alloy blower housing, multi-ring precision impeller and custom-designed dedicated drive motor. ·

* The impeller undergoes strict static & dynamic balance calibration; enclosed vortex compression design realizes both air blowing and vacuum suction, delivering completely oil-free & moisture-free clean air source. ·

* Full aluminum integrated casting construction ensures compact outline, lightweight body and low operating noise; all models run at fixed speed 2900r/min.

* Optimized internal airflow channel stabilizes high-pressure output and supports long-duration continuous operation.

PXG Model Features:

Material Properties

Boasting oil-free gas supply, dual blow/suction function, compact dimension and low noise, PXG ring blowers are widely used for matched mechanical equipment, wastewater treatment aeration, aquaculture oxygenation, gas transmission, industrial dust removal, bottle drying, automatic material feeding & collecting system.

Standard unit is equipped with general three-phase asynchronous motor; explosion-proof B - PXG variant with YB flameproof motor is available upon request for flammable volatile gas extraction.

Benefits

Standard PXG blower is applicable for conveying clean dry non-corrosive air; explosion-proof model can handle slightly combustible gas suction. Medium shall contain no sticky substance, liquid drop or bulky grit, working medium temperature ≤80℃.

Fan Structure

Explosion-proof B - PXG shares identical airflow performance, overall dimension and installation size with standard aluminum PXG blower, only drive motor is replaced with explosion-proof specification.

Model Selection

All PXG series fixed at 2900r/min, power 0.18~7.5kW, corresponding flow 20~478m³/h, total pressure 3.9~41.9kPa, vacuum 3.8~30kPa.

Model	Power(kW)	Rotation(r/min)	Volume(m³/h)	Pressure(kPa)	Vacuum(kPa)
PXG-0.18	0.18	2900	20~39	7.4~3.9	3.8
PXG-0.25	0.25	2900	23~45	8.2~4.3	4.2
PXG-0.37	0.37	2900	32~58	9.8~5.3	5.5
PXG-0.55	0.55	2900	36~65	11.2~6.7	6.8
PXG-0.75	0.75	2900	40~70	11.9~7.4	8
PXG-1.1	1.1	2900	62~98	13.8~8.5	11
PXG-1.5	1.5	2900	133~172	25.3~10.2	18
PXG-2.2	2.2	2900	170~210	27.6~15.1	20
PXG-3	3	2900	255~299	29.4~17.2	21
PXG-4	4	2900	276~328	32.6~22.8	26
PXG-5.5	5.5	2900	325~370	39.3~25.7	29
PXG-7.5	7.5	2900	429~478	41.9~29.8	30

Q1: What are the main applications of the PXG ring blower?
A1: It is widely used in supporting machinery, water treatment aeration, aquaculture, gas transmission, air dust removal, drying, feeding, and material collection.

Q2: What power range is available?
A2: The series includes models from 0.18kW to 7.5kW, suitable for various industrial needs.

Q3: Is the air output oil-free and water-free?
A3: Yes, the blower delivers clean, oil-free, water-free air, making it ideal for sensitive applications.

Q4: What is the operating speed of all models?
A4: All models operate at 2900 r/min, ensuring consistent performance.

Q5: Can the blower be used for both blowing and suction?
A5: Yes, it is designed as a dual-purpose blower, suitable for both positive pressure blowing and negative pressure suction.

Q6: Is the blower easy to install?
A6: Yes, the compact and lightweight design allows for easy installation in various locations.

Q7: What noise levels can be expected?
A7: The blower features low noise operation, suitable for environments where noise reduction is important.

Q8: How do I choose the right model for my application?
A8: Consider the required flow rate, pressure, vacuum level, and application type. The series offers a range of models with different capacities.

Q9: What maintenance is required for the PXG ring blower?
A9: Regular checks of the motor, impeller, and bearings, as well as cleaning of the intake filter, are recommended to ensure optimal performance.

Q10: What certifications does the PXG series have?
A10: The series meets international quality standards. CE-certified versions are available for European customers.
