Lightweight Body Portable Blower Fan Hand Grip Stand Industrial Axial Fan Low Noise
Lightweight Body Portable Blower Fan Hand Grip Stand Industrial Axial Fan Low Noise
Lightweight Body Portable Blower Fan Hand Grip Stand Industrial Axial Fan Low Noise
Lightweight Body Portable Blower Fan Hand Grip Stand Industrial Axial Fan Low Noise
Lightweight Body Portable Blower Fan Hand Grip Stand Industrial Axial Fan Low Noise
Lightweight Body Portable Blower Fan Hand Grip Stand Industrial Axial Fan Low Noise
Lightweight Body Portable Blower Fan Hand Grip Stand Industrial Axial Fan Low Noise
Lightweight Body Portable Blower Fan Hand Grip Stand Industrial Axial Fan Low Noise
Specifications
Motorpower :
0.5 kW - 30 kW
Type :
Centrifugal
Supply Ability :
100000 Sets/week
Place of Origin :
China
Operatingtemperature :
-20°C to 80°C
Noiselevel :
65 - 85 dB
Pressurerange :
500 - 5000 Pa
Mountingtype :
Horizontal / Vertical
Outletdiameter :
150 - 1000 mm
Application :
Ventilation, Dust Collection, Material Handling
Airflowcapacity :
1000 - 50000 CFM
Certification :
CE, UL, Rohs
MOQ :
1 set
Delivery Time :
2 two days for sampe order and 10 days for bulk order
Productname :
Industrial Centrifugal Fan
Speed :
500 - 3600 RPM
Material :
Steel / Stainless Steel
Payment Terms :
T/T
Brand Name :
Popula
Protectionclass :
IP54 / IP55
Powersupply :
220V / 380V / 440V
Inletdiameter :
200 - 1200 mm
Description

SHT High Quality Portable Axial Fan

* Model No.SHT2.5A to No.SHT4.0A of SHT type portable fan is composed of impeller, cylindrical casing, safety guard grille and integrated portable direct motor. ·

* The impeller is made of multi-piece forward curved axial blades, hub and reinforcing plate. ·

* These industrial portable blowing & exhaust fans are made of high-quality steel sheet, all impellers pass static and dynamic balance test, with excellent aerodynamic performance, high efficiency and stable running. ·

* The casing of SHT portable fan adopts integral fixed cylindrical structure, fitted with portable hand grip and supporting foot stand for flexible moving on site. ·

* The front & rear side of fan are equipped with fixed metal safety mesh, which can prevent accidental contact with rotating blades; matching telescopic flexible duct is optional for extended air delivery. ·

* The streamline inlet ensures air flows smoothly into impeller to improve ventilation efficiency.

SHT Model Features:

Material Properties

Featured by lightweight body, easy portability, low noise and stable air volume curve, SHT portable axial fans are ideal equipment for confined space air supply & exhaust, widely used for container ventilation, tunnel construction air exchange, mechanical workshop local exhausting, ship maintenance and emergency smoke removal of all kinds of engineering projects.

Standard SHT models from SHT2.5A to SHT4.0A are equipped with 220V single-phase motor; customized multiple voltages (110V/380V etc.) and explosion-proof versions are available on request. Explosion-proof BSHT series is configured with flameproof motor for exhausting volatile flammable gas.

Benefits

The transporting medium is clean air or other harmless non-explosive gas. With anti-explosion motor, BSHT explosion-proof portable fan can be applied for ventilation of volatile combustible gas. The conveyed medium shall not contain sticky substance or excessive granular dust, dust concentration ≤150mg/m³, medium temperature no higher than 80℃. The matched telescopic duct can connect with fan outlet to realize long-distance air feeding in narrow confined space.

Fan Structure

BSHT explosion-proof portable fan shares identical airflow performance, dimension and installation size with standard SHT series fan, only the driving motor is replaced with explosion-proof type.

Model Selection

Standard SHT2.5A~4.0A adopt integrated portable single-phase motor with fixed bracket; different voltage and explosion-proof options can be selected according to actual working condition.

Model Power(kW) Voltage(V) Rotation(r/min) Volume(m³/h) Pressure(Pa)
SHT2.5A 0.25 220 2800 1492~1822 154~134
SHT3.0A 0.37 220 2800 2578~3148 222~192
SHT3.5A 0.55 220 2800 3392~4202 285~224
SHT4.0A 0.90 220 2800 4054~5013 380~270

Q1: What are the main applications of the SHT portable fan?
A1: It is widely used for exhaust or blowing in containers, tunnels, machinery, and engineering projects.
Q2: What power supply options are available?
A2: Standard models use 220V power, with multi-voltage options available.
Q3: Is an explosion-proof version available?
A3: Yes, explosion-proof variants are available for use in hazardous environments.
Q4: Does the fan come with accessories?
A4: Yes, it includes a telescopic duct for flexible air delivery.
Q5: How portable is the fan?
A5: The compact, lightweight design with a handle allows for easy transport and setup.
Q6: What is the maximum airflow capacity of the SHT series?
A6: The largest model (SHT4.0A) delivers a maximum airflow of 5013 m³/h.
Q7: Is the fan suitable for continuous operation?
A7: Yes, the motor is designed for continuous use in industrial environments.
Q8: How do I choose the right model for my application?
A8: Consider the required airflow, pressure, and the size of the confined space. The series offers four models with different capacities.
Q9: What is the operating temperature range for the fan?
A9: The standard model is suitable for normal ambient temperatures, typically between -10℃ and 40℃.
Q10: What certifications does the SHT series have?
A10: The series meets international quality standards. CE-certified versions are available for European customers.
