China Best pp Filler Yarn for Wire Cable Filling
China Best pp Filler Yarn for Wire Cable Filling
China Best pp Filler Yarn for Wire Cable Filling
China Best pp Filler Yarn for Wire Cable Filling
China Best pp Filler Yarn for Wire Cable Filling
China Best pp Filler Yarn for Wire Cable Filling
China Best pp Filler Yarn for Wire Cable Filling
China Best pp Filler Yarn for Wire Cable Filling
China Best pp Filler Yarn for Wire Cable Filling
China Best pp Filler Yarn for Wire Cable Filling
Specifications
Place of Origin :
China, Jiangxi, China
Model Number :
3000D---700KD
MOQ :
100
Material :
100% Polypropylene or + 20---70% caco3
Diameter :
0.5----30mm
Yarn type :
fibrillated split yarn
Breaking strength :
>0.3 or 1.0 or 2.0 raw white,and flam retardant
Twist :
untwist or twist
Packing weight :
2.5---30kg/roll
Linear Density :
12000D, 18000D, 22000D, 28000D, 33000D, 48000D, 60000D, 70000D, 90000D
Weight per meter :
1.33+0.13 -0.13 to 10+1.0 -1.0 g/m
Breaking Strength :
24 to 180 kg
Breaking Elongation :
10%
Hot Shrinkage rate :
3%
Denier range :
3000D-300000D
Tensibility :
<20%
Shrinkage in hot air :
<6% at 120°C*30min
Tube size :
ID: 38-90mm, H: 220-440mm
Description

al-pet tape/pp foamed tape/pp filler cable material

1. 100% PP filler yarn

Linear Density

12000D

18000D

22000D

28000D

33000D

48000D

60000D

70000D

90000D

(weight)g/m

1.33+0.13

-0.13

2+0.2

-0.2

2.44+0.22

-0.22

3.11+0.31

-0.31

3.67+0.37

- 0.37

5.33+0.53

-0.53

6.67+0.67

-0.67

7.77+0.77

-0.77

10+1.0

-1.0

Diameter

(mm)

1.5

2

2.3

2.5

2.7

3.2

3.8

4.5

5

Breaking

Strength

(kg)

equal or more

24

36

44

56

66

96

120

140

180

(%)

Breaking Elongation

equal or more

10

10

10

10

10

10

10

10

10

Hot Shrinkage rate

(%)

3

3

3

3

3

3

3

3

3

China Best pp Filler Yarn for Wire Cable Filling

2.cheap cable pp filler yarn with mixed caco3 :

1-----5 PLY,2-----50MM,4-----8 TPM

this kinds of pp cable filler yarn price is the cheapest

China Best pp Filler Yarn for Wire Cable FillingChina Best pp Filler Yarn for Wire Cable Filling

China Best pp Filler Yarn for Wire Cable Filling

China Best pp Filler Yarn for Wire Cable FillingChina Best pp Filler Yarn for Wire Cable Filling

China Best pp Filler Yarn for Wire Cable Filling

Advantage: Cheap price, suitable for large cable.

Item

Linear Density

D

+/-10%

2------50mm

Denier:20000D---800KD

Breaking Strength

g/D

0.2---0.6

Breaking Elongation

%

20

Hot Shrinkage rate

%

6

100°C*1min.

Tube size

mm

1 ID: 90, H:255

2. ID:38,H:220

3. ID:50,H:270

4. ID:75, H:440

Packing

6----50KG/ROLL

3. pp twist wire cable pp filler yarn,20---80TPM,1----8MM

China Best pp Filler Yarn for Wire Cable Filling

China Best pp Filler Yarn for Wire Cable Filling

4.FR wire cable pp filler , LOI >29

China Best pp Filler Yarn for Wire Cable Filling

China Best pp Filler Yarn for Wire Cable Filling

Our advantage:

A. The best price at good quality
B. Excellent service and prompt delivery
C. Effective and attractive packaging

wire cable pp filler yarn

100% pp , pp filler Specificatioms
Item Unit standard Remark
Fineness D specification±8% 3000D-300000D
Breaking g/d >2
tenacity
Tensibility % <20
shrinkage % <6 120*30min
in hot air
Appearance Natural Color or White,color
obvious stations

In a wide range of denier from 3000D to 300KD,Widely used in wire and cable.These are sold in shrink-wrapped coreless rolls,rolled on paper cores and capable of working with continuing throughout their length.

pp+caco3 wire cable pp filler Specificatioms
Item Unit standard Remark
pp filler Fineness D specification±8% 3000D-300000D
pp filler Breaking g/d >0.3,>1g/d
tenacity
Tensibility % <20
shrinkage % <10 120*30min
in hot air
Appearance Natural Color or White,No
obvious stations

5.high tenacity polyester yarn and polyester thread

polyester sewing thread Spec. sewing thread weight

(g/spool)

sewing thread Length

(Y/spool)

840D/3

(0#)

 90 300----5000

630D/3

(5#)

 90 380----80000

500D/3

(10#)

 90 550---9000

250D/4

(20#)

 90 800-----12000

250D/3

(30#)

 90 1100---20000

250D/2

(40#)

 90 1600----25000

150D/3

(60#)

 90 1600------30000

120D/3

(80#)

 90 2100-----300000

6. aramid yarn:200D,400D,1000D,1500D,3000D

kelvar aramid yarn

aramid yarn is ahigh performance material,it comnines the characteristics of high strength and light weight. under the condition of equal weight,it is 5 times the strength of steel wire,2.5 times fiberglass.

China Best pp Filler Yarn for Wire Cable Filling

ARAMID YARN PROPERTY

aramid yarn Denier

(D)

aramid yarn Break

Strength

(kg)

Klongation

At Break

(%)

aramid yarn Modulus

(g/D)

1000

20

3.5

24.0

1500

32

3.8

24.0

400

9.5

3.3

24.0

20S/2

3

3.0

15.0

7. al-pet ,pp foamed tape

China Best pp Filler Yarn for Wire Cable Filling

...
