Custom-Tailor Nylon Mesh Filter Bag Linen Opening with Drawstring Micron 20um-500um for Fluid
Custom-Tailor Nylon Mesh Filter Bag Linen Opening with Drawstring Micron 20um-500um for Fluid
Custom-Tailor Nylon Mesh Filter Bag Linen Opening with Drawstring Micron 20um-500um for Fluid
Custom-Tailor Nylon Mesh Filter Bag Linen Opening with Drawstring Micron 20um-500um for Fluid
Custom-Tailor Nylon Mesh Filter Bag Linen Opening with Drawstring Micron 20um-500um for Fluid
Custom-Tailor Nylon Mesh Filter Bag Linen Opening with Drawstring Micron 20um-500um for Fluid
Custom-Tailor Nylon Mesh Filter Bag Linen Opening with Drawstring Micron 20um-500um for Fluid
Custom-Tailor Nylon Mesh Filter Bag Linen Opening with Drawstring Micron 20um-500um for Fluid
Specifications
Brand Name :
Share Filters
Model Number :
Nylon Mesh Filter Bag with Linen Edged Opening with Drawstring
Certification :
REACH
Place of Origin :
China
MOQ :
200pcs
Price :
USD0.30-USD2.9/pcs
Payment Terms :
T/T, L/C, D/P, Western Union, PayPay
Supply Ability :
1000meters/day
Delivery Time :
2-10 days Depends on Qty
Packaging Details :
Caron, Polybag
Product name :
Nylon mesh Filter bag with linen edged opening
Keyword :
Custom nylon mesh filter bag
Material :
PA6 single thread filter mesh
Micron rating :
2200μm-500μm
Stitch type :
Single stitch, double stitch, with or without wraped edge
Dimension :
Customized
Colour :
White
Application :
Liquid filtration
Description

Custom-Tailor Nylon Mesh Filter Bag Linen Opening with Drawstring Micron 50um-500um

Nylon filter mesh is popular due to its greater abrasion resistance comparative to the other three frequently used filter fabrics. Share Filters can make the nylon mesh filter bag according to custom's design. The mesh filter bags often found in filtration applications involving food grade liquid, abrasive dusts and wet abrasive solids where abrasion resistance plays an important factor.

Mesh Filter Bag Specification

Product name: Mesh filter bag Seam: Single, double, wrapped edge
Material: Nylon mesh, polyester mesh, PP mesh, polyethelene Drawstring With or without
Application: Food, beverage, milk, wine, paint, etc. Feature: Good chemical stability, open top for easy cleaning, reusable and durable
Dimension: Customized size Color: Nature
Micron rating: 20um-500um Package: Plastic bag, master carton

Proudct Picture

Custom-Tailor Nylon Mesh Filter Bag Linen Opening with Drawstring Micron 20um-500um for Fluid Custom-Tailor Nylon Mesh Filter Bag Linen Opening with Drawstring Micron 20um-500um for Fluid

Custom-Tailor Nylon Mesh Filter Bag Linen Opening with Drawstring Micron 20um-500um for Fluid Custom-Tailor Nylon Mesh Filter Bag Linen Opening with Drawstring Micron 20um-500um for Fluid

Custom-Tailor Nylon Mesh Filter Bag Linen Opening with Drawstring Micron 20um-500um for Fluid Custom-Tailor Nylon Mesh Filter Bag Linen Opening with Drawstring Micron 20um-500um for Fluid

The Benefit Features of Nylon Filter Mesh Bag:

  • Food grade material safe for food contact
  • Soft, smooth feeling
  • Washable and reusable
  • Easy cutting, sewing, and cleaning
  • High tensile strength
  • Precise and even mesh opening
  • Light weight
  • Elasticity and flexibility
  • Good resistance to alkalis
  • Temperatures up to 100°C
  • Hydrophilic

Nylon Filter Mesh Datasheet

Ref. No. Mesh Count Thread Diam. Mesh Opening Opening Area
mesh/cm mesh/inch µm µm %
JPP7 7 18 350 1079 57
JPP8 8 20 350 900 52
JPP9 9 24 250 860 60
JPP10 10 25 300 700 49
JPP12 12 30 250 583 49
JPP12 12 30 300 533 41
JPP14 14 35 300 414 34
JPP16 16 40 200 425 46
JPP16 16 40 250 375 36
JPP20 20 50 150 350 49
JPP20 20 50 200 300 36
JPP24 24 60 150 267 41
JPP28 28 70 120 237 44
JPP30 30 76 120 213 41
JPP32 32 80 100 213 46
JPP36 36 90 100 178 41
JPP40 40 100 100 150 36
JPP43 43 110 80 152 43
JPP48 48 120 80 130 38
JPP56 56 140 60 120 44
JPP59 59 150 60 110 42
JPP64 64 160 60 100 37
JPP72 72 180 50 90 41
JPP80 80 200 50 75 36
JPP100 100 250 40 60 36
JPP120 120 305 40 43 25
JPP130 130 330 40 37 23
JPP140 140 355 30 38 33.7
JPP150 150 381 30 34 30.25
JPP165 165 420 30 28 20.7
JPP180 180 460 30 25 19.5

How to select the right filter mesh? You Can Follow These Points
  • Mesh size or the size of the particle you need to filter
  • Mesh material (consider the working condition)
  • Mesh thread diameter, Mesh thickness
  • Opening area

Share Filters Manufacture Capabilities

Share Filters in-house capabilities include enhanced processing such as filter mesh slitting, punching, tubing, cutting,

injection molding and finishing of products. Share Filters can supply the nylon filter mesh, polyester mesh,

PP filter mesh, metallic mesh in different types to meet customs' filtration demands.

Custom-Tailor Nylon Mesh Filter Bag Linen Opening with Drawstring Micron 20um-500um for Fluid Custom-Tailor Nylon Mesh Filter Bag Linen Opening with Drawstring Micron 20um-500um for Fluid Custom-Tailor Nylon Mesh Filter Bag Linen Opening with Drawstring Micron 20um-500um for Fluid
Share Filter synthetic meshes are made from a variety of materials such as polyamide, polyester, polypropylene, etc. You can order by the roll or in pre-cut shapes. Ultrasonic and heat slitting is also used for manufacturing filtler mesh strips and resulting in a closed edge with very little material build up at the edge. Our cutting method include Laser cutting, Cold cutting, Heatt cutting, Punching. Professional cutting using custom-made tools that will not damage the materials.
Custom-Tailor Nylon Mesh Filter Bag Linen Opening with Drawstring Micron 20um-500um for Fluid Custom-Tailor Nylon Mesh Filter Bag Linen Opening with Drawstring Micron 20um-500um for Fluid Custom-Tailor Nylon Mesh Filter Bag Linen Opening with Drawstring Micron 20um-500um for Fluid
Sonic welding are accurate, clean. precision, sleeves and bags for blood filtration, biopsy bag and rosin bag are examples of applications that benefit from this technology. Share Filters sewing mesh filter products are carried out by highly skilled and experienced machinists, which ensure you get the right level of consistent quality. Custom plastic moulded filters combine precise filter mesh with polymer plastic. Injection moulding can take many forms and Share Filters is fully capable to help develop and produce the filters that will best suit your needs.

About Us

Share Filters has over 20 years of experience developing and manufacturing filter mesh and custom product for our customer's screen and filtration needs. We can offer the filter mesh and filter components services including slitting, cutting, welding, sewing and injection molding. Our customer base comes from a wide variety of industries including – Automotive, Home appliances, Food and beverage, Milling, Medical, Life Science and laboratory, Electronical as well as more general engineering, giving us a wealth of experience in many areas.

Industries We Serve

Custom-Tailor Nylon Mesh Filter Bag Linen Opening with Drawstring Micron 20um-500um for Fluid Custom-Tailor Nylon Mesh Filter Bag Linen Opening with Drawstring Micron 20um-500um for Fluid Custom-Tailor Nylon Mesh Filter Bag Linen Opening with Drawstring Micron 20um-500um for Fluid Custom-Tailor Nylon Mesh Filter Bag Linen Opening with Drawstring Micron 20um-500um for Fluid Custom-Tailor Nylon Mesh Filter Bag Linen Opening with Drawstring Micron 20um-500um for Fluid Custom-Tailor Nylon Mesh Filter Bag Linen Opening with Drawstring Micron 20um-500um for Fluid
Automotive Appliance Medical Food & Beverage Agriculture Environmental

Packing and Delivery

Custom-Tailor Nylon Mesh Filter Bag Linen Opening with Drawstring Micron 20um-500um for Fluid

Custom-Tailor Nylon Mesh Filter Bag Linen Opening with Drawstring Micron 20um-500um for Fluid

Contact Us

Share Filters provides some information for filter mesh possible applications, but there are too many functions for comprehensive descriptions of possible uses. Therefore, when considering a potential application in your particular industry, please consider contacting us who will work with engineers and product designers in choosing the right material and process for your specific projects.


Please connect with us now so we can learn more about your application and design specifications!
