Specifications
Brand Name :
Sumitomo Chemical
Model Number :
LCP E4008 MR
Certification :
MSDS
Place of Origin :
Japan
MOQ :
25KG
Price :
USD10-12KG
Payment Terms :
T/T
Supply Ability :
500TONS
Delivery Time :
7-15days
Packaging Details :
Plastic bag/Paper bag
Material Attribute :
40%Milled Glass Fiber Filler
Flame Rating :
V-0
Process :
Injection molding
Shrinkage Flow :
0.1%
Tensile Modulus :
11.9GPa
Flexural Strength :
105MPa
Elongation :
5%
Description

Products Description

High Heat Resistance LCP Plastic Material Aging Resistance LCP Plastic Resin

LCP Japan Sumitomo Chemical E4008 MR Size Stable Aging Resistance High Heat Resistance Weldable Flame Retardant Grade Liquid Crystal Polymer Automotive Parts Application Connector Applications

Sumitomo Chemical (SUMIKASUPER) LCP E4008MR is an injection molded glass fiber reinforced liquid crystal resin that exhibits high heat resistance in engineering plastics, with the following characteristics: Ultrasonic welding, irritating gas low to no, low viscosity, rigidity, high, high strength, recyclable materials, good formability, good adhesion, good chemical resistance, high heat resistance, low shrinkage, low water absorption or no water absorption, uses are: electrical/electronic applications, electrical components, optical data storage, connectors, spool.

product feature

LCP
E4008 MR
Product information
Part Marking Code >LCP-MGF40<
Color NC BK
Material Shape Pellets
Process Injection molding
FR V-0
Material Attribute 40%Milled Glass Fiber Filler
specification ·UL-746C F2 UL
UL File NO. E249884
Certificate UL
Physical property Standard Value Unit
Density ASTM D792 1.7 g/cm³
Shrinkage Flow INTERNAL METHOD 0.1 %
Shrinkage xFlow INTERNAL METHOD 1.32 %
Hardness Standard Value Unit
Rockwell Hardness R(Scale) ASTM D785 91
Mechanical behavior Standard Value Unit
Tensile Modulus ISO 527 11.9 GPa
Tensile Strength ASTM D638 105 MPa
Tensile Strength ISO 527 103 MPa
Elongation ASTM D638 5 %
Elongation ISO 527 3.1 %
Flexural Strength ASTM D790 139 MPa
Flexural Strength ISO 178 153 MPa
Flexural Modulus ASTM D790 12.3 GPa
Flexural Modulus ISO 178 12.9 GPa
Izod Un-notch Impact ASTM D256 520 J/m
Izod Un-notch Impact ISO 180 425 J/m
Charpy Un-notch Impact ISO 179 540 J/m
Thermal Standard Value Unit
HDT 1.8MPa ASTM D648 313 ℃
HDT 1.8MPa ISO 75 304 ℃
CLE Flow 50~250℃ INTERNAL METHOD 1.4E-5 cm/cm/℃
CLE xFlow 50~250℃ INTERNAL METHOD 6.2E-5 cm/cm/℃
Soldering Temperature INTERNAL METHOD 330 ℃
Electrical properties Standard Value Unit
Volume Resistivity ASTM D257 1E13 2.m
Surface Resistivity ASTM D257 1E16 Ω
Dielectric Strength Short Time Break Down ASTM D149 43 KV/mm
Dielectric Constant 1MHz ASTM D150 3.9
Dissipation Factor 1MHz ASTM D150 0.034
Arc Resistance ASTM D495 130 s
CTI IEC 60112 145 V
Flammability Standard Value Unit
Flame Rating NCWT BK0.30mm UL94 V-0
Flame Rating NC WT BK 0.75mm UL94 V-0
Flame Rating NCWT BK 1.5mm UL94 V-0
Flame Rating NCWT BK 3.0mm UL94 V-0
Limiting Oxygen Index JIS K7201 48 %
UL Standard Value Unit
UL FlameRating NC WT BK 0.30mm UL94 V-0
HWI NC WT BK 0.30mm UL746A 3 PLC

Application

High Heat Resistance LCP Plastic Material Aging Resistance LCP Plastic Resin High Heat Resistance LCP Plastic Material Aging Resistance LCP Plastic Resin

High Heat Resistance LCP Plastic Material Aging Resistance LCP Plastic Resin

Optical lighting

It used to manufacture large lampshade, protective glass, left and right eyepiece tubes of Optical instrument, etc., and can also be widely used as transparent materials on aircraft.

 High Heat Resistance LCP Plastic Material Aging Resistance LCP Plastic ResinElectronic appliances

It used in the manufacturing of insulation connectors, coil frames, sockets, insulation sleeves, telephone shells and parts, and battery shells for mining lamps, and so on.

 High Heat Resistance LCP Plastic Material Aging Resistance LCP Plastic ResinMechanical equipment

It used for manufacturing various gears, racks, worm gears, worms, bearings, cams, bolts, levers, crankshafts, ratchets, and can also be used as mechanical components such as shields

Physical Property Parameter​

High Heat Resistance LCP Plastic Material Aging Resistance LCP Plastic Resin

High Heat Resistance LCP Plastic Material Aging Resistance LCP Plastic Resin
