Products Description
 | PMMA France Arkema DR101 Impact Resistance UV Resistance Scratch Resistance High Light Transmittance Weather Resistance Excellent Mechanical Properties Suitable For Medical Field Lighting Fixtures |
Due to its high rigidity and high impact resistance, the PMMA DR101 is suitable for a wide range of industrial and consumer products, especially in applications requiring transparency and mechanical strength. |
product feature
PMMA | DR101 | Product information | Part Marking Code >PMMA< | FR | HB | | | Physical property | Standard | Value | Unit | Density | ASTM D792 | 1.16 | g/cm³ | Shrinkage Flow | ASTM D995 | 0.55 | % | Water Absorption 23℃24hr | ASTM D570 | 0.4 | % | Melt Index 230℃ 3.8kg | ASTM D1238 | 1.3 | g/10min | Hardness | Standard | Value | Unit | Rockwell Hardness M(Scale) | ASTM D785 | 45 | | Rockwell Hardness R(Scale) | ASTM D785 | 110 | | Mechanical behavior | Standard | Value | Unit | Tensile Modulus 23℃ | ASTM D638 | 2000 | MPa | Tensile Strength 23℃ | ASTM D638 | 42 | MPa | Elongation 23℃ | ASTM D638 | 35 | % | Flexural Strength 23℃ | ASTM D790 | 65 | MPa | Flexural Modulus 23℃ | ASTM D790 | 1820 | MPa | Izod Notch Impact 23℃ | ASTM D256 | 46 | J/m | Optical performance | Standard | Value | Unit | Transmittance | ASTM D1003 | 90 | % | Haze 3200μm | ASTM D1003 | 2.0 | % | Refractive Index | ASTM D542 | 1.49 | | Thermal | Standard | Value | Unit | HDT Annealed 1.8MPa | ASTM D648 | 87 | ℃ | Vicat Softening Temperature | ASTM D1525 | 105 | ℃ | CLE Flow | ASTM D696 | 1E-4 | cm/cm/℃ | Flammability | Standard | Value | Unit | Flame Rating 1.6mm | UL94 | HB | | |
Application
Optical lighting It used to manufacture large lampshade, protective glass, left and right eyepiece tubes of Optical instrument, etc., and can also be widely used as transparent materials on aircraft. | Electronic appliances It used in the manufacturing of insulation connectors, coil frames, sockets, insulation sleeves, telephone shells and parts, and battery shells for mining lamps, and so on. | Mechanical equipment It used for manufacturing various gears, racks, worm gears, worms, bearings, cams, bolts, levers, crankshafts, ratchets, and can also be used as mechanical components such as shields |
Physical Property Parameter


Company Profile:
Dongguan Pengchen plastic Co., LTD Was Established On November 15, 2022, Located Indongguan City.
The Company Covers An Area Of More Than 400 Square Meters, And The Three warehouses Cover A Total Area Of 110000 Square Meters, With 50-60 Employees.
Our Company Is An Expert In The Field Of Plastic Raw Materials. A Professional Supplier Of modified Engineering Plastics Raw Materials. Engaged In R&d, Production And Sales Of engineering Plastics.
We Provide High-quality Plastic Raw Materials With Low Order quantity, Reasonable Price And Fast Delivery.
our Product Range Includes Engineering Materials And General Mater
Warehouse:
FAQ
How about our package?
1.All the packing can be customized.
2.Plastic bags for inner packing, good quality moisture-proof bags for outer packing.
3.We generally make 25kgs per small bag by accurate weight, this will be very convenient for the customer using. It’s very easy to
handle the dosage.
What are our business principles?
1.For the trial order, 1tons will be acceptable.
2.We will do our best for the customer as long as you choosing us.
3.We promise to solve all the problems during trading process, our quality and the products will be approved by your side.
What are the advantages of our shipping and delivery?
1.We make sure all the products will be inspected strictly before loading.
2.We will make the shipment within 7 days after confirm the payment.
3.We will recommend the best suitable shipping company for our customer from different countries. Saving cost for our client
Application | Electronics electrical appliances mobile phones cars |
Grade | Injection Grade,Extrusion Grade |
OEM/ODM | Accepted |
