Polyamide PA12 LCL-3H, a Non-static Electricity-resistant, Long Carbon Fiber Reinforced, Conductive Plastic
Polyamide PA12 LCL-3H, a Non-static Electricity-resistant, Long Carbon Fiber Reinforced, Conductive Plastic
Polyamide PA12 LCL-3H, a Non-static Electricity-resistant, Long Carbon Fiber Reinforced, Conductive Plastic
Polyamide PA12 LCL-3H, a Non-static Electricity-resistant, Long Carbon Fiber Reinforced, Conductive Plastic
Polyamide PA12 LCL-3H, a Non-static Electricity-resistant, Long Carbon Fiber Reinforced, Conductive Plastic
Polyamide PA12 LCL-3H, a Non-static Electricity-resistant, Long Carbon Fiber Reinforced, Conductive Plastic
Polyamide PA12 LCL-3H, a Non-static Electricity-resistant, Long Carbon Fiber Reinforced, Conductive Plastic
Polyamide PA12 LCL-3H, a Non-static Electricity-resistant, Long Carbon Fiber Reinforced, Conductive Plastic
Polyamide PA12 LCL-3H, a Non-static Electricity-resistant, Long Carbon Fiber Reinforced, Conductive Plastic
Polyamide PA12 LCL-3H, a Non-static Electricity-resistant, Long Carbon Fiber Reinforced, Conductive Plastic
Specifications
Brand Name :
PA12
Model Number :
PA12 LCL-3H
Certification :
MSDS
Place of Origin :
German
MOQ :
25KG
Price :
USD6.5-7KG
Payment Terms :
T/T
Supply Ability :
500T
Delivery Time :
7-15days
Packaging Details :
PE Plastic/Paper Bag
Material :
PA12 LCL-3H
Color :
natural color
Application :
Electronic and electrical applications
Shape :
Pellets
Package :
25 KG PE Bag
DELIVERY TIME :
7-15days
MOQ :
25KG
Description

Products Description

Polyamide PA12 LCL-3H, a Non-static Electricity-resistant, Long Carbon Fiber Reinforced, Conductive Plastic

Polyamide PA12 LCL-3H, a Non-static Electricity-resistant, Long Carbon Fiber Reinforced, Conductive Plastic

product feature

,

The scientific name of PA12 is polydodecactam, also known as nylon 12.
PA12 is a semi-crystalline - crystalline thermoplastic material, the basic raw material of its polymerization is butadiene, which can rely on petrochemical.

PA12 is a good electrical insulator, and like other polyamides, it does not affect the insulation performance due to moisture. It has good impact resistance mechanical and chemical stability.

PA12 LCL-3H

Part Marking Code >PA12<
Color NC
Process Injection molding
FR HB
specification ·UL
Features ·Short cycle time
UL File NO. E102178
Certificate (so0
Physical property Standard Value Unit
Density 23℃ ISO 1183 1020 kg/m³
Water Absorption 23℃50RH ISO 62 0.6 %
Water Absorption In Water ISO 62 1.4 %
Melt Index 190℃2.16kg ISO 1133 3 cm³/10min
Melt Index 230℃ 2.16kg ISO 1133 10 cm/10min
Hardness Standard Value Unit
Rockwell Hardness R(Scale) ISO 2039 109
Mechanical behavior Standard Value Unit
Tensile Modulus 23℃ ISO 527 1300 MPa
Tensile Strength Yield 23℃ ISO 527 42 MPa
Tensile Strength Break 23℃ ISO 527 60 MPa
Elongation Yield 23℃ ISO 527 10 %
Elongation Break 23℃ ISO 527 50 %
Charpy Notch Impact 23℃ ISO 179 5 kJ/m²
Charpy Notch Impact-30℃ ISO 179 6 kJ/m²
Charpy Un-notch Impact 23℃ ISO 179 NB kJ/m²
Charpy Un-notch Impact -30℃ ISO 179 NB kJ/m²
Themal Standard Value Unit
HDT 0.45MPa ISO 75 120 ℃
HDT 1.8MPa ISO 75 50 ℃
Melting Temperature Method A ISO 3146 178 C
CLE ISO 11359 1.4E-4 cm/cm/℃
Electrical properties Standard Value Unit
Volume Resistivity 23℃50RH IEC 60093 1E13 Ωcm
Dielectric Strength IEC 60243 28 KV/mm
Flammablity Standard Value Unit
Flame Rating NCBK 1.5mm UL94 HB
UL Standard Value Unit
UL FlameRating NC BK 1.5mm UL94 HB
RTI Elec NC BK 1.5mm UL746B 65 ℃

RTI Imp NC BK1.5mm UL746B 65 ℃

Application

Polyamide PA12 LCL-3H, a Non-static Electricity-resistant, Long Carbon Fiber Reinforced, Conductive Plastic Polyamide PA12 LCL-3H, a Non-static Electricity-resistant, Long Carbon Fiber Reinforced, Conductive Plastic

Polyamide PA12 LCL-3H, a Non-static Electricity-resistant, Long Carbon Fiber Reinforced, Conductive Plastic

Optical lighting

It used to manufacture large lampshade, protective glass, left and right eyepiece tubes of Optical instrument, etc., and can also be widely used as transparent materials on aircraft.

Polyamide PA12 LCL-3H, a Non-static Electricity-resistant, Long Carbon Fiber Reinforced, Conductive Plastic

Electronic appliances

It used in the manufacturing of insulation connectors, coil frames, sockets, insulation sleeves, telephone shells and parts, and battery shells for mining lamps, and so on.

Polyamide PA12 LCL-3H, a Non-static Electricity-resistant, Long Carbon Fiber Reinforced, Conductive Plastic

Mechanical equipment

It used for manufacturing various gears, racks, worm gears, worms, bearings, cams, bolts, levers, crankshafts, ratchets, and can also be used as mechanical components such as shields

Physical Property Parameter​

Polyamide PA12 LCL-3H, a Non-static Electricity-resistant, Long Carbon Fiber Reinforced, Conductive Plastic

Company Profile:

Dongguan Pengchen plastic Co., LTD Was Established On November 15, 2022, Located Indongguan City.

The Company Covers An Area Of More Than 400 Square Meters, And The Three warehouses Cover A Total Area Of 110000 Square Meters, With 50-60 Employees.
Our Company Is An Expert In The Field Of Plastic Raw Materials. A Professional Supplier Of modified Engineering Plastics Raw Materials. Engaged In R&d, Production And Sales Of engineering Plastics.
We Provide High-quality Plastic Raw Materials With Low Order quantity, Reasonable Price And Fast Delivery.
our Product Range Includes Engineering Materials And General Mater
Polyamide PA12 LCL-3H, a Non-static Electricity-resistant, Long Carbon Fiber Reinforced, Conductive Plastic Polyamide PA12 LCL-3H, a Non-static Electricity-resistant, Long Carbon Fiber Reinforced, Conductive Plastic

Warehouse:

Polyamide PA12 LCL-3H, a Non-static Electricity-resistant, Long Carbon Fiber Reinforced, Conductive Plastic
Polyamide PA12 LCL-3H, a Non-static Electricity-resistant, Long Carbon Fiber Reinforced, Conductive Plastic Polyamide PA12 LCL-3H, a Non-static Electricity-resistant, Long Carbon Fiber Reinforced, Conductive Plastic
FAQ
How about our package?
1.All the packing can be customized.
2.Plastic bags for inner packing, good quality moisture-proof bags for outer packing.
3.We generally make 25kgs per small bag by accurate weight, this will be very convenient for the customer using. It’s very easy to
handle the dosage.
What are our business principles?
1.For the trial order, 1tons will be acceptable.
2.We will do our best for the customer as long as you choosing us.
3.We promise to solve all the problems during trading process, our quality and the products will be approved by your side.
What are the advantages of our shipping and delivery?
1.We make sure all the products will be inspected strictly before loading.
2.We will make the shipment within 7 days after confirm the payment.
3.We will recommend the best suitable shipping company for our customer from different countries. Saving cost for our client

Application Electronics electrical appliances mobile phones cars
Grade Injection Grade,Extrusion Grade
OEM/ODM Accepted
