DC Battery Charger with integrated safety instructions emphasizing correct battery type selection and proper ventilation
DC Battery Charger with integrated safety instructions emphasizing correct battery type selection and proper ventilation
DC Battery Charger with integrated safety instructions emphasizing correct battery type selection and proper ventilation
DC Battery Charger with integrated safety instructions emphasizing correct battery type selection and proper ventilation
Specifications
Brand Name :
Oxiang /OEM
Model Number :
B2B1290
Certification :
CE.RoHS,FCC
Place of Origin :
Shenzhen
Max Input Power :
910W
Temperature Compensation :
-3mv/℃/2V
Starter Battery Type :
Lead-acid
Temperature Sensor :
optional
Output :
24v
Working Temperature :
-20℃~+60℃
Battery Capacity :
30A
Charging Port :
1 port
Mppt Solar :
12V 90A
System Voltage :
12V/ 24V auto recognition
Voltage :
24V-12V
Waterproof :
IP66
Start Battery Voltage :
12V
Battery Type Compatibility :
Lead Acid, AGM, Gel, Lithium
Board Battery :
12V
Description
INSTALLATION ATTENTION
• Do not expose the DC/DC charge tr o rain or snow.
• Do not use the DC/DC charger if it has received a sharp blow, been dropped,
has cracks or openings in the case, or is damaged in any other way.
• Do not install the charger near a heat source.
• This charger should not be installed in an airtight or poorly ventilated area.
• Do not attempt to open the DC/DC charger. There are no user serviceable parts
except for user replaceable fuses.
• Do not use the DC/DC charger with damaged cables.
• It is strictly forbidden to disassemble the charger and/or modify the housing in
any way.
!
CONNECTIONS ATTENTION
•
• It is important to choose the correct battery type, a wrong choice can cause irreversible
damage, The LITHIUM charging cycle is only compatible with LiFePo4 batteries with
integrated BMS (Battery Management System).
Maintenance
• If necessary, the fuses must be replaced by identical products.
• This charger cannot be disassembled and the electronic board is inaccessible.
• Therefore, with the exception of the fuses, all on-site maintenance is prohibited.
• Disconnect the DC power supply before servicing, cleaning or working on
circuits connected to the DC/DC booster.
• Once disconnected, isolate the battery connection terminals.
• It is important to ensure that the area around the battery is well ventilated.
• It is important to ensure that the battery voltage matches the output voltage
• Always use ungrounded batteries. If necessary, the battery grounding connection
should be made last.
DC Battery Charger with integrated safety instructions emphasizing correct battery type selection and proper ventilation
