Polcd 2.8 Inch 240*320 Resolution 50pin Tft Lcd Screen Display Module 2.8 Small Size Lcd Panel
Polcd 2.8 Inch 240*320 Resolution 50pin Tft Lcd Screen Display Module 2.8 Small Size Lcd Panel
Polcd 2.8 Inch 240*320 Resolution 50pin Tft Lcd Screen Display Module 2.8 Small Size Lcd Panel
Polcd 2.8 Inch 240*320 Resolution 50pin Tft Lcd Screen Display Module 2.8 Small Size Lcd Panel
Polcd 2.8 Inch 240*320 Resolution 50pin Tft Lcd Screen Display Module 2.8 Small Size Lcd Panel
Polcd 2.8 Inch 240*320 Resolution 50pin Tft Lcd Screen Display Module 2.8 Small Size Lcd Panel
Polcd 2.8 Inch 240*320 Resolution 50pin Tft Lcd Screen Display Module 2.8 Small Size Lcd Panel
Polcd 2.8 Inch 240*320 Resolution 50pin Tft Lcd Screen Display Module 2.8 Small Size Lcd Panel
Polcd 2.8 Inch 240*320 Resolution 50pin Tft Lcd Screen Display Module 2.8 Small Size Lcd Panel
Polcd 2.8 Inch 240*320 Resolution 50pin Tft Lcd Screen Display Module 2.8 Small Size Lcd Panel
Specifications
Brand Name :
Polcd
Model Number :
P028HK9853-24P
Certification :
RoHS, ISO9001
Place of Origin :
Shenzhen, China
MOQ :
1 piece
Price :
Please contact us for latest price
Payment Terms :
T/T, L/C, Credit card, PayPal
Supply Ability :
500,000 piece per week
Delivery Time :
1~7 working days
Packaging Details :
20 cm * 30 cm * 40 cm
Screen Size :
2.8 inch
Resolution :
240RGB(H)x320(V)
Brightness (cd/m²) :
200 nit
Interface :
4wire SPI
Driver Ic :
JD9853
Display area :
43.20(H)x57.60(V)
Description

Parameter:

Model P028HK9853-24P
Screen Size 2.8 inch
Number of Pixel 240RGB(H)x320(V)
Display area 43.20(H)x57.60(V)mm
Pixel pitch 0.180(H)x0.180(V)mm
Pins 24 pins
Outline Dimension 50.00x69.20x2.30mm
Pixel arrangement RGB Vertical Stripe
Display mode Normally black
Viewing Direction(eye) ALL
Gray inversion direction --
Display Color 262K
Luminance(cd/m2) 200 nit
Contrast Ratio 1200:1
Surface treatment --
Interface 4-line SPI
Back-light LED Side-light type
Drive IC JD9853
Operation Temperature -20~70℃
Storage Temperature -30~80℃
