Polcd 3.2 inch 240x320 LCD Module Display Spi interface TFT Panel ST7789V 3.2'' LCD Screen
Polcd 3.2 inch 240x320 LCD Module Display Spi interface TFT Panel ST7789V 3.2'' LCD Screen
Polcd 3.2 inch 240x320 LCD Module Display Spi interface TFT Panel ST7789V 3.2'' LCD Screen
Polcd 3.2 inch 240x320 LCD Module Display Spi interface TFT Panel ST7789V 3.2'' LCD Screen
Polcd 3.2 inch 240x320 LCD Module Display Spi interface TFT Panel ST7789V 3.2'' LCD Screen
Polcd 3.2 inch 240x320 LCD Module Display Spi interface TFT Panel ST7789V 3.2'' LCD Screen
Polcd 3.2 inch 240x320 LCD Module Display Spi interface TFT Panel ST7789V 3.2'' LCD Screen
Polcd 3.2 inch 240x320 LCD Module Display Spi interface TFT Panel ST7789V 3.2'' LCD Screen
Specifications
Model Number :
P032H013
Payment Terms :
T/T,L/C,Credit card,PayPal
Resolution :
240*320
Driver Ic :
ST7789V
Supply Ability :
40,000 PCS per day
Size (inch) :
3.2
MOQ :
1 piece
Delivery Time :
1-7 working days
Contrast Ratio :
500:1
Price :
Please contact us for latest price
Brightness (cd/m²) :
300
Interface :
4 Line SPI
Packaging Details :
FCL size: 40*30*20cm / Sample Packaging: 20*18*13cm
Brand Name :
Polcd
Certification :
RoHS, ISO9001
Place of Origin :
Shenzhen, China
Description

TFT LCD is a technology widely used in monitors and TVs, and its full name is Thin Film Transistor Liquid Crystal Display. It is a liquid crystal display technology that controls the brightness of the backlight through changes in the electric field of liquid crystal molecules to display images and text.

LCD screens are made up of many pixels, each of which consists of a thin film transistor (TFT) and a liquid crystal cell. TFT is a switch that can control the transparency of the liquid crystal cell by changing the voltage. When the electric field is changed, the liquid crystal cell twists and redirects the light passing through it, thereby controlling the amount and color of light passing through the pixels to form an image.

Parameter:

Model

P032H013

Screen Size

3.2 inch

Number of Pixel

240RGB(H)x320(V)

PIN

10 pin

Display area

48.60(H)x64.80(V)mm

Pixel pitch

0.2025(H)x0.2025(V)mm

Outline Dimension

55.04x77.50x2.60mm

Pixel arrangement

RGB Vertical Stripe

Display mode

Normally White

Viewing Direction(eye)

12 0'CLOCK

Display Color

262K

Luminance(cd/m2)

300 nit

Contrast Ratio

500:1

Interface

4Wire SPI

Back-light

LED Side-light type

Drive IC

ST7789V

Operation Temperature

-20~70 ℃

Storage Temperature

-30~80 ℃
