Polcd 300 Nit 3.5 Inch Capacitive Touch Screen ILI9488 Touch Screen Tft Lcd
Polcd 300 Nit 3.5 Inch Capacitive Touch Screen ILI9488 Touch Screen Tft Lcd
Polcd 300 Nit 3.5 Inch Capacitive Touch Screen ILI9488 Touch Screen Tft Lcd
Polcd 300 Nit 3.5 Inch Capacitive Touch Screen ILI9488 Touch Screen Tft Lcd
Polcd 300 Nit 3.5 Inch Capacitive Touch Screen ILI9488 Touch Screen Tft Lcd
Polcd 300 Nit 3.5 Inch Capacitive Touch Screen ILI9488 Touch Screen Tft Lcd
Polcd 300 Nit 3.5 Inch Capacitive Touch Screen ILI9488 Touch Screen Tft Lcd
Polcd 300 Nit 3.5 Inch Capacitive Touch Screen ILI9488 Touch Screen Tft Lcd
Specifications
Brand Name :
Polcd
Model Number :
P035C018-TP
Certification :
RoHS, ISO9001
Place of Origin :
Shenzhen, China
MOQ :
1 piece
Price :
Please contact us for latest price
Payment Terms :
T/T,L/C,Credit card,PayPal,D/A,D/P,Western Union,MoneyGram
Supply Ability :
40,000 PCS per day
Delivery Time :
1-7 working days
Packaging Details :
FCL size: 40*30*20cm / Sample Packaging: 20*18*13cm
Size (inch) :
3.5
Resolution :
320*480
Brightness (cd/m²) :
300
PIN :
50 pin
Driver Ic :
ILI9488
interface :
RGB MCU SPI
Description

What can we expect from this one? Before this question it is better to know some information about this TFT Touch Screen. Screen size is 3.5 inch. A very common and hot selling size for small size TFT display. The TFT LCD offers a physical resolution of 320 * 480, clear enough for most scenes to be used. 250 nits allow this lcd to work well indoors.


Parameter:

Model

P035C018-TP

Screen Size

3.5 inch

Number of Pixel

320RGB(H)x480(V)

Display area

48.96(H)x73.44(V)mm

Pixel pitch

0.153(H)x0.153(V)mm

Pin

50 pin

Outline Dimension

54.48x84.71x2.25mm

Pixel arrangement

RGB Vertical Stripe

Display mode

Normally White

Viewing Direction(eye)

12 0'CLOCK

Display Color

262k

Luminance(cd/m2)

300 nit

Contrast Ratio

500:1

Interface

MCU 8/16bit RGB 18bit SPI 3/4wire

Back-light

LED Side-light type

Drive IC

ILI9488

Operation Temperature

-20~70℃

Storage Temperature

-30~80℃


Supported by MCU 16bit, this type of TFT LCD can be used in many applications. ILI9488 is the driver IC of the tft lcd. The operation temperature is -20°C to 70°C and the storage temperature is -30°C to 80°C which compliant with industry standards.

Polcd 300 Nit 3.5 Inch Capacitive Touch Screen ILI9488 Touch Screen Tft Lcd

Q: Is there a Touch Panel (Touch Screen) on the display?
A: We can offer you the RTP (Resistive Touch Panel) and CTP (Capacitive Touch Panel) if you need.

Q: Where can I get the datasheet, initialization code, product drawings, test reports and other technical files?
A: Please contact our sales and we will provide any files if you need.

Q: How long can I get the goods?
A: It depends on the quantity. Our inventory is mainly raw materials, semi-finished and a small number of finished products. Samples available in stock will be sent in 3 days; Small batch delivery takes 15-20 working days include producing; Large batch delivery takes 20-30 working days. We will list the time cost for you before order.

Q: Can I trust the quality? We want good quality first.
A: Our company has a professional Quality Control Department, and all products are 100% inspected prior to ship. We welcome all the customers from the wolrd visiting our factory for checking any time.
