Rotary Single Action Pneumatic Actuator 90 Degree Actuator For Valve Automation
Rotary Single Action Pneumatic Actuator 90 Degree Actuator For Valve Automation
Rotary Single Action Pneumatic Actuator 90 Degree Actuator For Valve Automation
Rotary Single Action Pneumatic Actuator 90 Degree Actuator For Valve Automation
Rotary Single Action Pneumatic Actuator 90 Degree Actuator For Valve Automation
Rotary Single Action Pneumatic Actuator 90 Degree Actuator For Valve Automation
Specifications
Brand Name :
OEM
Place of Origin :
China
Certification :
CE.ATEX.ISO9001.SIL3
MOQ :
1PCS
Model Number :
32mm to 400mm
Price :
10-2000USD
Payment Terms :
T/T
Supply Ability :
1000pcs per day
Delivery Time :
3-7 days
Packaging Details :
Foam+Carton Box+Wooden Case
Name :
Single Action Pneumatic Actuator
Actuator Rotation Angle :
90°
Application :
Ball Valve, Butterfly Valve
Actuator Application :
Valve Automation
Structure :
Rack And Pinion Pneumatic Actuator
Metarial :
Extruded Aluminum Alloy
Body Color :
Silver
Connection :
ISO 5211,DIN 3337
Description
Single Effect 90° Pneumatic Rotary Actuator for Valve Automation
Product Overview

The Single Action Pneumatic Actuator is a high-quality actuator designed for reliable performance in industrial applications. Engineered to operate with hydraulic oil or water as the media, it offers compatibility with various systems.

Featuring a precise 90° rotation angle, this actuator provides accurate control and positioning, making it ideal for applications requiring specific rotation angles. The extruded aluminum alloy construction combines lightweight design with robust strength for demanding applications.

Key Features
  • Connection: ISO 5211, DIN 3337
  • Actuator Accessories: Limit Switch, Solenoid Valve, Filter Regulator
  • Body Color: Silver
  • Usage: Pneumatic Actuator Control For Valves
  • Material: Aluminum Alloy
  • Spring return mechanism for safety and reliability
Technical Specifications
Material Extruded Aluminum alloy
Rotary Angle 0~90 degree
Structure Rack and pinion rotary actuator
Working Pressure 2~8bar
Surface Treatment Hard anodizing
Working Temperature Normal: -20°C to +80°C
High: -15°C to +150°C
Low: -40°C to +80°C
Connection NAMUR, ISO5211 and DIN3337
Application Ball valve, butterfly valve, and rotary machine
Cup Color Options Grey, black, sky blue, dark blue, red, orange
Applications

This durable single effect pneumatic actuator is suitable for various valve automation needs. Certified with CE, ATEX, ISO9001, and SIL3 standards, it's designed for industrial environments and process control applications.

With a minimum order quantity of 1 piece, it's accessible for both small and large projects. The spring return feature ensures quick operation, making it ideal for critical applications.

Frequently Asked Questions
What is the brand name of this Single Action Pneumatic Actuator?
The brand name is OEM.
Where is this Single Action Pneumatic Actuator manufactured?
The product originates from China.
Does this Single Action Pneumatic Actuator come with any certifications?
Yes, it is certified with CE, ATEX, ISO9001, and SIL3.
What is the minimum order quantity for purchasing this Single Action Pneumatic Actuator?
The minimum order quantity is 1 piece.
Is this Single Action Pneumatic Actuator suitable for high-risk environments?
Yes, it is certified with SIL3, making it suitable for use in high-risk environments.
