Explosionproof Air Driven Double Diaphragm Pump Plastic Food Grade

Air Driven Double Diaphragm Pump Advantages:

• Provide stall-free, ice-free zero leak operation.
• Epoxy-coated air section for tough environmental conditions.
• Low shear force , not easy to damage the material structure.
• Bolt joint design provides even sealing pressure for optimal performance
• Modular air valve,low pulsation operation,providing smooth and rapid changeover.
• No electricity . It's safe and realiable while using in the flammable and explor place .
• Diversity of material,no rotating parts,applicable to various erosive situations.
• Can pump corrosive , volatile, flammable, poisonous fluids with particles and high viscosity.
• Delivery lift and flow can pass the pneumatic valve open to realize the stepless adjustment.

Air Driven Double Diaphragm Pump Parameters

A 50 X X - X X X - X (model selection)

Form of pipe mouth:A-BSP B-NPT(F) C-Flange

Diaphragm material:9 – Santoprene H – Hytrel T - PTFE/Santoprene

Ball material:9 -Santoprene H – Hytre T – PTFE A - Acetal

Ball seat material:P/K –Polypropylene/Kynoar SS –Stainless Steel

Pump material: SS –Stainless Steel AL –Aluminum Alloy CI- Carbon Steel P/K –Polypropylene/Kynoar

Maximum Applied Temperature Limits (diaphragm / ball / seal material)

Acetal ···············································40°- 150°F (4.4- 65.5°C)

Santoprene·········································-40°- 225°F (-40°- 107.2°C) ·················································40°- 220°F (4.4°- 104°C) Nitrile·················································10°- 180°F (-12°- 82°C) Viton··················································-40°- 350°F (-40°-176.6°C) Hytrel·················································-20°-150°F (-12°- 93°C) Kynar·················································10°-200°F (-28.9°- 65.5°C) Polypropylene·······································32°- 175°F (0-79.4°C)
