Stainless Steel Air Driven Double Diaphragm Pump High Volume Delivery
Stainless Steel Air Driven Double Diaphragm Pump High Volume Delivery
Specifications
Brand Name :
BSK
Model Number :
BSKA80AL-P99-A
Place of Origin :
China
MOQ :
10 Unit(s)
Price :
Negotiable
Payment Terms :
FOB T/T
Supply Ability :
1000 Unit(s) Per Month
Delivery Time :
10days
Packaging Details :
Woods
Guarantee: :
one year
Advantage :
High Volume Delivery
Name :
Air Driven Double Diaphragm Pump
Maximum lift :
70m
Weight :
103kg
Material :
Stainless Steel
Pressure :
High Pressure
Description

Stainless Steel Air Driven Double Diaphragm Pump High Volume Delivery

Air Driven Double Diaphragm Pump ADVANTAGES

  • Self Priming, No need of foot valve.
  • Variable flow with same pump.
  • Can be submerge.
  • Less stock of spare to be maintain.
  • No skill person is needed to operation and repair pump.
  • Light weight,
  • No rotation no wear & tear hence low maintenance.
  • Pump can run dry.
  • Stop Automatic on closing of discharge Valve.
  • Can handle 2 to 10 mm size solid particles.
  • Also Can be used upto accuracy 3 to 5 %.
  • No motor, No fire.
  • In short very simple and versatile pump.

Air Driven Double Diaphragm Pump Application


• Sauces, Purees & Beverages
• Prepared Foods
• Fruits, Vegetables & Condiments
• Bio-pharmaceutical
• Pharmaceutical products
• Health & personal care
• Confectionary
• Chromatography, Separation, Purification
• High Purity product transfer
• Filter press feed pumps

Air Driven Double Diaphragm Pump Parameters

Item Description Unit Reference Figure
1 Maximum air inlet pressure Mpa 0.83
2 Maximum flow rate L/Min 903
3 Maximum lift M 70
4 Maximum outlet pressure Mpa 0.83
5 Maximum particle size mm 9
6 Weight kg 103
7 Noise level db ＜70

Air Driven Double Diaphragm PumpSpecifications
1. Non leakage
2. Good self priming performance
3. Convey all kinds of medium

A 80X X - X X X - X (model selection)

Form of pipe mouth:A-BSP B-NPT(F) C-Flange

Diaphragm material:9 – Santoprene H – Hytrel T - PTFE/Santoprene

Ball material:9 -Santoprene H – Hytre T – PTFE A - Acetal

Ball seat material:P/K –Polypropylene/Kynoar SS –Stainless Steel

Pump material: SS –Stainless Steel AL –Aluminum Alloy CI- Carbon Steel P/K –Polypropylene/Kynoar

Stainless Steel Air Driven Double Diaphragm Pump High Volume Delivery

3" Flow diagram

Stainless Steel Air Driven Double Diaphragm Pump High Volume Delivery
