AIRTAC Type Solenoid Valve Air Valve 4V310-10 DC 12V 24V AC 110V 220V
AIRTAC Type Solenoid Valve Air Valve 4V310-10 DC 12V 24V AC 110V 220V
Specifications
Brand Name :
BRANDO
Model Number :
4V310-10
Certification :
None
Place of Origin :
CHINA
MOQ :
300pcs
Price :
Negotiation
Payment Terms :
T/T,Western Union,MoneyGram
Supply Ability :
100000 pcs per month
Delivery Time :
Negotiation
Packaging Details :
Inner Box,Carton,Pallet
Port Size :
In=Out=3/8'', Exhaust=1/4''
Pressure Range :
0.15 To 0.8 MPa
Body Material :
Aluminum Alloy
Valve Type :
5 Way 2 Position
Max Pressure Resistance :
1.5MPa (215PSI)
Fluid :
Air
Voltages :
12VDC, 24VDC, 24VAC, 110VAC, 220VAC
Description

AIRTAC Type Solenoid Valve Air Valve 4V310-10 DC 12V 24V AC 110V 220V


Pneumatic solenoid valves generally have a spool design. They consist of an aluminum body with a cylindrical hole. The different ports of the valve connect to the cylinder. A sliding spool in the cylinder has several seals along its length. By sliding the spool back and forth through the cylinder, different ports can be connected or closed off. Pneumatic solenoid valves are appointed with two numbers. The first number shows how many ports the valve has, and the second number is the amount of states. For example, a 2/2-way valve has two ports (in/out) and two states (open/closed). A 5/2-way valve has five ports and two states. Directional valves usually have two, three, or five ports.


Technical Data of 4V300 Series Solenoid Valve:

Model
4V310-08
4V320-08
4V330C-08
4V330E-08
4V330P-08
4V310-10
4V320-10
4V330C-10
4V330E-10
4V330P-10
Fluid
Air (to be filtered by 40 μm filter element)
Acting
internal pilot or external pilot
Port Size
in=out=exhaust=1/4''
in=out=3/8'', exhaust=1/4''
Orifice Size
4V310-10, 4V320-10: 28.0mm² (Cv=1.65)
4V330C-10: 21.3mm² (Cv=1.25)
Vlave Type
5 way 2 position
5 way 3 postion
5 way 2 position
5 way 3 position
Operating Pressure
0.15 to 0.8 MPa (21 to 114 psi)
Proof Pressure
1.2MPa (175psi)
Temperature
-20 to +70℃
Body Material
Aluminum Alloy
Max Frequency
5 cycle/sec
3 cycle/sec
5 cycle/sec
3 cycle/sec
Voltages
12VDC, 24VDC, 24VAC, 110VAC, 220VAC


Dimension of 4V310-10 Pneumatic Solenoid Valve:

AIRTAC Type Solenoid Valve Air Valve 4V310-10 DC 12V 24V AC 110V 220V


Product video of 4V310-10 Pneumatic Solenoid Valve:

Production Video of Pneumatic Solenoid Valves:


More Pneumatic Products for you to choose:

AIRTAC Type Solenoid Valve Air Valve 4V310-10 DC 12V 24V AC 110V 220VAIRTAC Type Solenoid Valve Air Valve 4V310-10 DC 12V 24V AC 110V 220VAIRTAC Type Solenoid Valve Air Valve 4V310-10 DC 12V 24V AC 110V 220VAIRTAC Type Solenoid Valve Air Valve 4V310-10 DC 12V 24V AC 110V 220V

Solenoid Operator Manifold Silencer Pneumatic Hose Fittings


Focus on your demands, Offer you best solution:

√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing

Welcome to your any question and inquiry!
