Solenoid Valve FDF2AK NO Series Refrigeration Valve Sanhua Type 1/4''
Solenoid Valve FDF2AK NO Series Refrigeration Valve Sanhua Type 1/4''
Solenoid Valve FDF2AK NO Series Refrigeration Valve Sanhua Type 1/4''
Solenoid Valve FDF2AK NO Series Refrigeration Valve Sanhua Type 1/4''
Solenoid Valve FDF2AK NO Series Refrigeration Valve Sanhua Type 1/4''
Solenoid Valve FDF2AK NO Series Refrigeration Valve Sanhua Type 1/4''
Solenoid Valve FDF2AK NO Series Refrigeration Valve Sanhua Type 1/4''
Solenoid Valve FDF2AK NO Series Refrigeration Valve Sanhua Type 1/4''
Specifications
Brand Name :
BRANDO
Model Number :
FDF2AK
Certification :
None
Place of Origin :
CHINA
MOQ :
5pcs
Price :
Negotiation
Payment Terms :
T/T,Western Union,MoneyGram
Supply Ability :
100000 pcs per month
Delivery Time :
Negotiation
Packaging Details :
Inner Box,Carton,Pallet
Product Name :
Refrigeration Solenoid Valve
Tube OD (mm) :
1/4'' (Φ6.35mm)
Orifice Size :
1.8mm
Wiring Type :
Flying Leads
Function :
2 Way Normally Open
Operation :
Direct Operated
Voltage :
24VDC, 24VAC, 110VAC, 220VAC
Application :
Air Conditioner, Heat Pump, Ice Maker, Freezer, Cooler, Etc
Working Pressure :
0 To 21 Bar
Proof Pressure :
45 Bar
Refrigerant :
HCFC, HFC, Etc
Description

Solenoid Valve FDF2AK NO Series Refrigeration Valve Sanhua Type 1/4''


FDF2AK series solenoid valves are direct operated, normally open solenoid valves, mainly used in refrigerant control of various
devices such as refrigerating and freezing systems, air conditioners and heat pumps.

Features:
1. Compact design
2. Low energy consumption
3. Excellent operation performance

General Specifications:
1. Applicable for all common HCFC, HFC refrigerants such as:

R22, R134a, R404A, R407C, R410A, R507, R407A/F, R448A/R449A, R452A, R450A/R513A1)
2. Medium temperature TS min./max.: -30°C / 120°C
3. Ambient temperature: -30°C / +50°C
4. Relative humidity: 0 to 95% RH
5. Installation position:
1) Liquid, suction and discharge line
2) Coil upwards, coil axis ±15° tolerance versus vertical axis
3) Flow direction corresponds to the arrow


Technical Data:

Solenoid Valve FDF2AK NO Series Refrigeration Valve Sanhua Type 1/4''

Model No
Function
Operation
Orifice
Kv (m³/h)
MOP
Max.
OPD
Min.
OPD
Connection
OD
FDF2AK01
2 Way
NO
Direct Acting
1.8mm
0.05
45 bar
21 bar
0 bar
1/4''
(Φ6.35mm)


Our Production:

Solenoid Valve FDF2AK NO Series Refrigeration Valve Sanhua Type 1/4''
