SMC Type VX2120-01 Direct Operated 2 Way Solenoid Valve 1/8'' AC220V DC24V
SMC Type VX2120-01 Direct Operated 2 Way Solenoid Valve 1/8'' AC220V DC24V
SMC Type VX2120-01 Direct Operated 2 Way Solenoid Valve 1/8'' AC220V DC24V
SMC Type VX2120-01 Direct Operated 2 Way Solenoid Valve 1/8'' AC220V DC24V
SMC Type VX2120-01 Direct Operated 2 Way Solenoid Valve 1/8'' AC220V DC24V
SMC Type VX2120-01 Direct Operated 2 Way Solenoid Valve 1/8'' AC220V DC24V
Specifications
Brand Name :
BRANDO
Model Number :
VX2120-01
Certification :
None
Place of Origin :
CHINA
MOQ :
1 pc
Price :
Negotiation
Payment Terms :
T/T,Western Union,MoneyGram
Supply Ability :
100000 pcs per month
Delivery Time :
Negotiation
Packaging Details :
Inner Box,Carton,Pallet
Port Size :
1/8''
Orifice Size :
3mm
Operation :
2 Way, Normally Closed
Pressure Range :
0 To 1 MPa
Body Material :
Brass
Action :
Direct Acting
Voltage :
12VDC, 24VDC, 24VAC, 110VAC, 220VAC
Description

SMC Type VX2120-01 Direct Operated 2 Way Solenoid Valve 1/8'' AC220V DC24V


The VX2 series is 2 port direct solenoid valve for general purpose air, medium vacuum and water. Available body materials include brass or stainless steel with port size up to 1/2 inch.NBR seal is used as standard and FKM or EPDM is optional. Flow rate ranges from Cv of 0.23 to 2.21.


1. IP65 enclosure
2. Normally Closed and Normally Open type available, Class B coil
3. Body material: brass, stainless steel
4. Working pressure range: 0 to 1 MPa


Main Dimension of VX2 Series Solenoid Valve:

SMC Type VX2120-01 Direct Operated 2 Way Solenoid Valve 1/8'' AC220V DC24V

VX Series
A
B
C
D
VX2122-01
25
40
70
1/8''
VX2222-02
1/4''
VX2120-01
45
1/8''
VX2120-06
45
1/4''
VX2260-03
40
48
80
3/8''
VX2360-03
3/8''
VX2360-04
48
68
110
1/2''


Technical Data of VX2 Series Solenoid Valve:

Model
VX2112-01
VX2112-02
VX2120-01
VX2120-02
VX2260-03
VX2360-03
VX2360-04
Orifice Size
2mm
2mm
3mm
3mm
10mm
10mm
10mm
Port Size
1/8''
1/4''
1/8''
1/4''
3/8''
3/8''
1/2''
Medium
Water, Oil, Gas, Steam
Action
Direct Acting
NC/NO
Normally Open
Normally Closed
Body Material
Brass, Stainless Steel
Seal Material
NBR, FKM
Pressure
Range
0 to 1.0Mpa
Temp. Range
NBR: (-5 to +80℃), FKM: (-5 to +150℃)


Brando Factory Production of Solenoid Valves:




More Pneumatic Products for you to choose:


2/2 Way Pneumatic Valves 3/2 Way Pneumatic Valves 5/2 Way Pneumatic Valves 5/3 Way Pneumatic Valves
Namur Solenoid Valves Air Pilot Valves Pneumatic Cylinders Silencers and Fittings
SMC Type VX2120-01 Direct Operated 2 Way Solenoid Valve 1/8'' AC220V DC24V SMC Type VX2120-01 Direct Operated 2 Way Solenoid Valve 1/8'' AC220V DC24VSMC Type VX2120-01 Direct Operated 2 Way Solenoid Valve 1/8'' AC220V DC24V
