DN10 3/8 Inch 300 bar High Pressure Solenoid Valve Stainless Steel 220V 24V
DN10 3/8 Inch 300 bar High Pressure Solenoid Valve Stainless Steel 220V 24V
DN10 3/8 Inch 300 bar High Pressure Solenoid Valve Stainless Steel 220V 24V
DN10 3/8 Inch 300 bar High Pressure Solenoid Valve Stainless Steel 220V 24V
DN10 3/8 Inch 300 bar High Pressure Solenoid Valve Stainless Steel 220V 24V
DN10 3/8 Inch 300 bar High Pressure Solenoid Valve Stainless Steel 220V 24V
Specifications
Delivery Time :
Negotiation
Certification :
None
Packaging Details :
Inner Box,Carton,Pallet
Price :
Negotiation
Product Name :
High Pressure Solenoid Valve
Orifice Size :
10mm
Voltage :
12VDC, 24VDC, 24VAC, 110VAC, 220VAC
Place of Origin :
CHINA
MOQ :
1 pc
Payment Terms :
T/T,Western Union,MoneyGram
Body Material :
Stainless Steel
Port Size :
G3/8''
Brand Name :
BRANDO
Supply Ability :
100000 pcs per month
Function :
2 Way Normally Closed
Max Working Pressure :
300 Bar
Diaphragm Material :
PEEK
Model Number :
H12S10B03
Description

DN10 3/8 Inch 300 bar High Pressure Solenoid Valve Stainless Steel 220V 24V


Technical Data:


Model No. Port Size Orifice Size CV Working pressure (bar) Body Seal Function
220VAC
110VAC
24VAC
24VDC
 12VDC
H12S10B03 3/8'' 10mm 3.5 6 to 360 6 to 300 6 to 250 SS304 PEEK 2 Way, NC
H12S15B04 1/2'' 15mm 4.7
H12S20B06
3/4''
 20mm 7
H12S25B25 1'' 25mm 10


Main Dimension:

DN10 3/8 Inch 300 bar High Pressure Solenoid Valve Stainless Steel 220V 24V

Our Production:


DN10 3/8 Inch 300 bar High Pressure Solenoid Valve Stainless Steel 220V 24V


FAQ:


Question 1: What is a solenoid valve used for?
Answer 1: A solenoid valve is used to open, close, mix, or divert media in an application. They are used in a wide variety of
applications.

Question 2: How can you tell if your solenoid valve is bad?
Answer 2: If the solenoid valve fails to open or close, is partially open, makes a humming noise or has a burned-out solenoid coil, you need to troubleshoot the valve solenoids.

Question 3: How do I choose a solenoid valve?
Answer 3: When choosing a solenoid valve, it is important to know your media. Depending upon the media and flow requirement, choose the material, port size, orifice size, temperature, pressure, voltage, response time and certification required for your application.
