Solenoid valve Steam US-50 UNI-D Type 2'' 2L-50 Steam Brass Solenoid Valve 24V 220V
Solenoid valve Steam US-50 UNI-D Type 2'' 2L-50 Steam Brass Solenoid Valve 24V 220V
Specifications
Supply Ability :
100000 pcs per month
Port Size :
2''
Brand Name :
BRANDO
Action :
Piston Piloted Operated
Model Number :
US-50
Voltage :
12VDC, 24VDC, 24VAC, 110VAC, 220VAC
MOQ :
1 pc
Delivery Time :
Negotiation
Diaphragm Material :
PTFE
Payment Terms :
T/T,Western Union,MoneyGram
Orifice Size :
50mm
Body Material :
Brass
Price :
Negotiation
Working Pressure Range :
0.1 To 1.5 MPa
Function :
2 Way Normally Closed
Working Fluids :
Hot Water, Steam
Certification :
None
Place of Origin :
CHINA
Temperature Range :
-20 To +185 ℃
Packaging Details :
Inner Box,Carton,Pallet
Description

Solenoid valve Steam US-50 UNI-D Type 2'' 2L-50 Steam Brass Solenoid Valve 24V 220V


Product Features of 2L series Steam Solenoid Valve:

The UNI-D US-50 Solenoid Valve is a 2-inch, two-way, pilot-operated piston solenoid valve designed primarily for steam, hot water, and heavy oil applications.


Key Specifications


1. Working Medium: Hot Water, Steam, etc
2. Working Pressure Range: 0.1 to 1.5 MPa
3. Seal Material: PTFE
4. Body Material: Brass, Stainless Steel
5. Port Size: 3/8'', 1/2'', 3/4'', 1'', 1 1/4'', 1 1/2'', 2''
6. Orifice Size: 17mm, 22mm, 30mm, 50mm
7. Operation: Piston Pilot Operated

8. Function: 2 Way Normally Closed
9. Coil Voltage Option: 12VDC, 24VDC, 24VAC, 110VAC, 220VAC (50/60Hz)


Technical Data of 2L series Steam Solenoid Valve:​

2L Series Model
2L-10
2L-15
2L-20
2L-25
2L-35
2L-40
2L-50
US Series Model
US-10
US-15
US-20
US-25
US-35
US-40
US-50
Orifice Size
17
17
17
22
30
30
50
Port Size
3/8''
1/2''
3/4''
1''
1-1/4''
1-1/2''
2''
Medium
Hot Water, Steam
Action
Piston Pilot Operated
Function
2 Way Normally Closed
Body Material
Brass, Stainless Steel
Seal Material
PTFE
Pressure
Range
0.1 to 1.5 MPa
Temp. Range
-20 to +185℃
Coil Voltages
12VDC, 24VDC, 24VAC, 110VAC, 220VAC


Dimension of 2L series Steam Solenoid Valve:

Solenoid valve Steam US-50 UNI-D Type 2'' 2L-50 Steam Brass Solenoid Valve 24V 220V

US Series
2L Series
A
B
C
Port Size
US-10
2L-10
82
42
146
3/8''
US-15
2L-15
1/2''
US-20
2L-20
3/4''
US-25
2L-25
90
54
162
1''
US-35
2L-35
110
75
185
1 1/4''
US-40
2L-40
1 1/2''
US-50
2L-50
120
77
195
2''
