4V320-08 Airtac Type Pneumatic Air Control Valve 4V320-1/4 24V 220V
4V320-08 Airtac Type Pneumatic Air Control Valve 4V320-1/4 24V 220V
Specifications
Brand Name :
Brando
Model Number :
4V320-08
Certification :
CE
Place of Origin :
China
MOQ :
100 PCS
Price :
Negotiation
Payment Terms :
T/T, PayPal, Western Union
Supply Ability :
200000 pcs per month
Delivery Time :
Negotiation
Packaging Details :
Individual box, Carton, Pallet
Type :
5/2 Way, Double Solenoid
Port Size :
In=Out=Exhaust=1/4''
Pressure Range :
0.15 to 0.8MPa (21 to 114PSI)
Max Pressure Resistance :
1.5MPa (215PSI)
Body Material :
Aluminum Alloy
Max. Frequency :
4 Cycle / Second
Description

4V320-08 Airtac Type Pneumatic Air Control Valve 4V320-1/4 24V 220V

2 position 5 way pneumatic solenoid valve usually has a single solenoid valve and a double solenoid valve, that is, a single solenoid valve has one coil and a double solenoid valve has two coils. The pneumatic solenoid valve is used to control the flow of compressed air. In fact, the two kind of pneumatic solenoid valves have similar working principles.

We will now introduce you to single and double solenoid valves. They are internally pilot operated and can be powered by 12V DC, 24V DC, 110V AC or 220V AC. Pneumatic solenoid valve can be opened and closed quickly and safely, with high reliability and low price. The following table lists the specifications of 5/2 way pneumatic solenoid valves with single and double coils for your reference.

Data of 4V300 Series Pneumatic Solenoid Valves:

Model
4V310-08
4V320-08
4V330C-08
4V330E-08
4V330P-08
4V310-10
4V320-10
4V330C-10
4V330E-10
4V330P-10
Fluid
Air(to be filtered by 40 μ m filter element)
Acting
Internal pilot or external pilot
Port Size
In=Out=Exhaust=1/4''
In=Out=3/8'' Exhaust=1/4''
Orifice Size
25.00 mm2 (Cv=1.40)
18.00 mm2 (Cv=1.00)
30.00 mm2 (Cv=1.68)
18.00 mm2 (Cv=1.00)
Valve Type
5 port 2 position
5 port 3 position
5 port 2 position
5 port 3 position
Operating Pressure
0.15~0.8MPa(21~114psi)
Proof Pressure
1.5MPa(215psi)
Temperature ℃
-20~70
Material of Body
Aluminum alloy
Max. frequency
4 cycle/sec
4 cycle/sec
4 cycle/sec
4 cycle/sec

Dimension of 4V320-08 Pneumatic Solenoid Valve:

4V320-08 Airtac Type Pneumatic Air Control Valve 4V320-1/4 24V 220V

Product video of 4V320-08 Pneumatic Solenoid Valve:


Production Video of Pneumatic Solenoid Valve:

More Pneumatic Products for you to choose:

4V320-08 Airtac Type Pneumatic Air Control Valve 4V320-1/4 24V 220V4V320-08 Airtac Type Pneumatic Air Control Valve 4V320-1/4 24V 220V4V320-08 Airtac Type Pneumatic Air Control Valve 4V320-1/4 24V 220V4V320-08 Airtac Type Pneumatic Air Control Valve 4V320-1/4 24V 220V

Solenoid Operator Manifold Silencer Pneumatic Hose Fittings

Focus on your demands, Offer you best solution:

√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing

Welcome to your any question and inquiry!
