Pneumatic Actuator 3 Piece Flanged Ball Valve 1'' DN25 Stainless Steel
Pneumatic Actuator 3 Piece Flanged Ball Valve 1'' DN25 Stainless Steel
Specifications
Brand Name :
Brando
Model Number :
Q641
Certification :
CE
Place of Origin :
China
MOQ :
1 pc
Price :
Negotiation
Payment Terms :
T/T, PayPal, Western Union
Supply Ability :
50000 pcs per month
Delivery Time :
Negotiation
Packaging Details :
Inner boxes, Carton, Pallet
Structure :
Ball
Power :
Pneumatic
Pipe Connection :
Flanged
Body Material :
Stainless Steel (304, 316)
Seal Material :
PTFE, TFM
Working Medium :
Neutral Gas, Air
Orifice Size :
DN15 to DN200
Description

Pneumatic Actuator 3 Piece Flanged Ball Valve 1'' DN25 Stainless Steel

Pneumatic ball valves are used to control the flow of a media, liquid or gas, by means of a rotating ball with a bore. The rotating ball is controlled by a pneumatic actuator that is capable of turning it. A ball valve is one of the most common valves due to their simple operation, reliability, long service life, and wide range of application uses.

2-way pneumatic ball valves have 2 ports, an inlet and an outlet. The media flows from one direction to the other and the valve is used to open or close the flow. A 2-way ball valve is commonly called a shut off valve.

3-way pneumatic ball valves have 3 ports. The bore in the ball is not straight, but rather in an L or T formation. This allows for various circuit functions (flow directions) for the valve. It can be used to distribute, mix, or divert flow in the desired direction. Therefore, any of the 3 ports can be an inlet or an outlet.

Technical Data of Pneumatic Ball Valve:

Pneumatic Ball Valve
Electric Ball Valve
Air Pressure: 0.4 to 0.8 MPa
Electric Actuator Power:
380VAC, 220VAC, 110VAC (50/60Hz), 24VDC
Electric Actuator Input: 4-20mA. DC
Control Medium: Neutral Gas, Air
Ambient Temperature: -20 to +60℃
Medium Temperature: -20 to +180℃
UPVC Ball Valve: -10 to +45℃
CPVC Ball Valve: -15 to +90℃
Normal Seal's Working Temperature: PTFE (-20 to +180℃), TFM (-30 to +230℃)
Manufacturing Standard: GB, ISO, ANSI, BS, DIN

Main Dimension of Pneumatic Ball Valve:

Pneumatic Actuator 3 Piece Flanged Ball Valve 1'' DN25 Stainless Steel

Pneumatic Actuator 3 Piece Flanged Ball Valve 1'' DN25 Stainless Steel

More Pneumatic Actuator Valves for you to choose:

Pneumatic Ball Valves
Pneumatic Actuator 3 Piece Flanged Ball Valve 1'' DN25 Stainless Steel Pneumatic Actuator 3 Piece Flanged Ball Valve 1'' DN25 Stainless Steel Pneumatic Actuator 3 Piece Flanged Ball Valve 1'' DN25 Stainless Steel Pneumatic Actuator 3 Piece Flanged Ball Valve 1'' DN25 Stainless Steel
Pneumatic Actuator 3 Piece Flanged Ball Valve 1'' DN25 Stainless Steel Pneumatic Actuator 3 Piece Flanged Ball Valve 1'' DN25 Stainless Steel Pneumatic Actuator 3 Piece Flanged Ball Valve 1'' DN25 Stainless Steel Pneumatic Actuator 3 Piece Flanged Ball Valve 1'' DN25 Stainless Steel
Pneumatic Butterfly Valves
Pneumatic Actuator 3 Piece Flanged Ball Valve 1'' DN25 Stainless Steel Pneumatic Actuator 3 Piece Flanged Ball Valve 1'' DN25 Stainless Steel Pneumatic Actuator 3 Piece Flanged Ball Valve 1'' DN25 Stainless Steel Pneumatic Actuator 3 Piece Flanged Ball Valve 1'' DN25 Stainless Steel

Focus on your demands, Offer you best solution:

√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing

Welcome to your any question and inquiry!
