PVC Pneumatic Actuator Plastic Butterfly Valve 2'' DN50 UPVC CPVC
PVC Pneumatic Actuator Plastic Butterfly Valve 2'' DN50 UPVC CPVC
Specifications
Brand Name :
Brando
Model Number :
D671
Certification :
CE
Place of Origin :
China
MOQ :
1 pc
Price :
Negotiation
Payment Terms :
T/T, PayPal, Western Union
Supply Ability :
50000 pcs per month
Delivery Time :
Negotiation
Packaging Details :
Inner boxes, Carton, Pallet
Orifice Size :
DN50 to DN200
Structure :
Butterfly
Power :
Pneumatic
Connection Type :
Wafer
Body Material :
UPVC, CPVC
Seal Material :
Rubber
Working Medium :
Neutral Gas, Air
Description

PVC Pneumatic Actuator Plastic Butterfly Valve 2'' DN50 UPVC CPVC

BRANO’s range of pneumatically controlled butterfly valves, which are used to control the flow of a media remotely. They can have either a lug or wafer connection style. Based on the actuator design (single or double acting) the actuator will open and close the butterfly valve with compressed air (single acting uses a spring to either open or close the valve). The butterfly valve has a disc that rotates with the actuator to open or close the butterfly valve. The butterfly valve design allows for good sealing properties, durability, and reliability for your application. Pneumatic actuators are a reliable solution and often used to control larger valves than electric actuators at a lower investment cost. There are various housings, seals, and sizes of pneumatically controlled butterfly valves to allow you to find the right one for your application.

Technical Data of Pneumatic Butterfly Valve:

Pneumatic Butterfly Valve
Electric Butterfly Valve
Air Pressure: 0.4 to 0.8 MPa
Electric Actuator Power:
380VAC, 220VAC, 110VAC (50/60Hz), 24VDC
Electric Actuator Input: 4-20mA. DC
Control Medium: Neutral Gas, Air
Ambient Temperature: -20 to +60℃
Manufacturing Standard: GB, ISO, ANSI, BS, DIN

Main Dimension of Pneumatic Butterfly Valve:

PVC Pneumatic Actuator Plastic Butterfly Valve 2'' DN50 UPVC CPVC

PVC Pneumatic Actuator Plastic Butterfly Valve 2'' DN50 UPVC CPVC

More Pneumatic Actuator Valves for you to choose:

Pneumatic Ball Valves
PVC Pneumatic Actuator Plastic Butterfly Valve 2'' DN50 UPVC CPVC PVC Pneumatic Actuator Plastic Butterfly Valve 2'' DN50 UPVC CPVC PVC Pneumatic Actuator Plastic Butterfly Valve 2'' DN50 UPVC CPVC PVC Pneumatic Actuator Plastic Butterfly Valve 2'' DN50 UPVC CPVC
PVC Pneumatic Actuator Plastic Butterfly Valve 2'' DN50 UPVC CPVC PVC Pneumatic Actuator Plastic Butterfly Valve 2'' DN50 UPVC CPVC PVC Pneumatic Actuator Plastic Butterfly Valve 2'' DN50 UPVC CPVC PVC Pneumatic Actuator Plastic Butterfly Valve 2'' DN50 UPVC CPVC
Pneumatic Butterfly Valves
PVC Pneumatic Actuator Plastic Butterfly Valve 2'' DN50 UPVC CPVC PVC Pneumatic Actuator Plastic Butterfly Valve 2'' DN50 UPVC CPVC PVC Pneumatic Actuator Plastic Butterfly Valve 2'' DN50 UPVC CPVC PVC Pneumatic Actuator Plastic Butterfly Valve 2'' DN50 UPVC CPVC

Focus on your demands, Offer you best solution:

√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing

Welcome to your any question and inquiry!
