3/2 Way Direct Acting Stainless Steel Solenoid Valve 1/8'' 1/4'' 12V 24V 110V 220V
3/2 Way Direct Acting Stainless Steel Solenoid Valve 1/8'' 1/4'' 12V 24V 110V 220V
Specifications
Brand Name :
BRANDO
Model Number :
C1
Certification :
CE, ISO
Place of Origin :
China, Ningbo
MOQ :
1 pc
Price :
Negotiation
Payment Terms :
T/T, Western Union,Paypal
Supply Ability :
50000 pcs per month
Delivery Time :
4 to 7 working days
Packaging Details :
Inner Box, Carton, Pallet
Port Size :
1/8'', 1/4''
Orifice Size :
1.5mm, 2mm
Function :
3 Way Normally Closed, 3 Way Normally Open
Operation :
Plunger Direct Acting
Body Material :
Stainless Steel
Seal Material :
NBR, EPDM, FKM
Temperature Range :
NBR: -10 to +80 ℃, EPDM: -30 to +120 ℃, FKM: -30 to +150 ℃
Voltage :
12VDC, 24VDC, 24VAC, 110VAC, 220VAC
Description

3/2 Way Direct Acting Stainless Steel Solenoid Valve 1/8'' 1/4'' 12V 24V 110V 220V

3 way solenoid valve has 3 ports and 2 switching states (open or closed) and are electromechanically controlled. With 3 ports and 2 switching states, the valve can be either NC (normally closed), NO (normally open), mixing, distributing or universal. NC is most common: the valve has 1 input, 1 output, and an exhaust port. The output connects to exhaust with no power, and with power the input is connected to the output moving the media. They can also be designed as normally open (power to close) or bi-stable (latching). It is important to first select the housing material of your valve to ensure it is suitable for the media that the valve will be controlling.


Technical Data of Solenoid Valve:

3/2 Way Direct Acting Stainless Steel Solenoid Valve 1/8'' 1/4'' 12V 24V 110V 220V

Port Size

(inch)

Orifice Size

(mm)

Kv Value

(m³/h)

 Pressure Range Body Material Seal Material Dimension
A F K
3 Way Normally Closed, Direct Acting
1/8'' 1.5 0.05 0 to 16 bar

Brass

Stainless Steel

 NBR: -10 to +80℃
EPDM: -30 to +120℃
FKM: -30 to +150℃		 40 25 81
2 0.12 0 to 10 bar 40 25 81
1/4'' 1.5 0.05 0 to 16 bar 40 25 84
2 0.12 0 to 10 bar 40 25 84


BRANDO Solenoid Valve Production Video:

More Solenoid Valves for you to choose:

Brass Solenoid Valve
3/2 Way Direct Acting Stainless Steel Solenoid Valve 1/8'' 1/4'' 12V 24V 110V 220V 3/2 Way Direct Acting Stainless Steel Solenoid Valve 1/8'' 1/4'' 12V 24V 110V 220V 3/2 Way Direct Acting Stainless Steel Solenoid Valve 1/8'' 1/4'' 12V 24V 110V 220V 3/2 Way Direct Acting Stainless Steel Solenoid Valve 1/8'' 1/4'' 12V 24V 110V 220V
3/2 Way Direct Acting Stainless Steel Solenoid Valve 1/8'' 1/4'' 12V 24V 110V 220V 3/2 Way Direct Acting Stainless Steel Solenoid Valve 1/8'' 1/4'' 12V 24V 110V 220V 3/2 Way Direct Acting Stainless Steel Solenoid Valve 1/8'' 1/4'' 12V 24V 110V 220V 3/2 Way Direct Acting Stainless Steel Solenoid Valve 1/8'' 1/4'' 12V 24V 110V 220V
Stainless Steel Solenoid Valve
3/2 Way Direct Acting Stainless Steel Solenoid Valve 1/8'' 1/4'' 12V 24V 110V 220V 3/2 Way Direct Acting Stainless Steel Solenoid Valve 1/8'' 1/4'' 12V 24V 110V 220V 3/2 Way Direct Acting Stainless Steel Solenoid Valve 1/8'' 1/4'' 12V 24V 110V 220V 3/2 Way Direct Acting Stainless Steel Solenoid Valve 1/8'' 1/4'' 12V 24V 110V 220V


Focus on your demands, Offer you best solution:

√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing

Welcome to your any question and inquiry!
