Diaphragm For BFEC DMF-Z-50S DMF-Y-50S 2'' Pulse Valve Repair Kit
Diaphragm For BFEC DMF-Z-50S DMF-Y-50S 2'' Pulse Valve Repair Kit
Specifications
Brand Name :
Brando
Model Number :
D50
Certification :
CE
Place of Origin :
China
MOQ :
1 set
Price :
Negotiation
Payment Terms :
L/C, T/T, Western Union, Paypal, MoneyGram
Supply Ability :
200000 pcs per month
Delivery Time :
4-7 Days
Packaging Details :
Plastic Bags, Cartons, Pallet
Product Name :
Pulse Valve Diaphragm
Diaphragm Material :
NBR
1 Set :
1x Main Diaphragm, 1x Secondary Diaphragm, 2x Springs
Suitable Valve Port Size :
2''
Suitable Valves :
DMF-Z-50S, DMF-Y-50S
Packaging :
Individual Plastic Bag Sealed
Description

Diaphragm For BFEC DMF-Z-50S DMF-Y-50S 2'' Pulse Valve Repair Kit

The below diaphragm is used to repair 2'' BFEC DMF-Z-50S, DMF-Y-50S pulse jet valve. The complete 1 set including 1 pc main diaphragm, 1 pc secnodary diaphragm, 2 pcs springs. Pulse jet valves are operated by integral solenoid pilot operator. When the valve is energised, the trapped air above pulse valve diaphgram is quickly exhausted causing fast opening of main diaphragm valve. When the pilot operated valve is de - energised , air escapes through bleed hole of main pulse valve to balance the diaphragm pressure and instantly closes the valve.

Ordering Code No of BFEC Pulse Valve Diaphragm:

Ordering Code
Fitted Valve Code
Port Size
DTY
All Double Diaphragm Pulse Valve
Secondary Diaphragm
D20A
DMF-Z-20, DMF-ZM-20
3/4''
D25
DMF-Z-25, DMF-ZM-25, DMF-ZF-25,
DMF-Y-25, DMF-T-20
3/4'' & 1''
D40
DMF-Z-40S, DMF-Y-40S, DMF-ZF-40S,
DMF-ZM-40S, DMF-T-25S
1'' & 1-1/2''
D50
DMF-Z-50S, DMF-Y-50S, DMF-T-50S
2''
D62
DMF-Z-62S, DMF-Y-62S
2-1/2''
D76
DMF-Z-76S, DMF-Y-76S
3''
D102
DMF-Z-102S DMF-Y-102S
4''
D102A
DMF-Y-102SA
4''
DZL-20B
DMF-ZL-B
3/4''


Dimension of 2'' Pulse Valve Diaphragm Repair Kit:

Diaphragm For BFEC DMF-Z-50S DMF-Y-50S 2'' Pulse Valve Repair Kit

Video of 2'' Pulse Valve Diaphragm Repair Kit:

Brando Production of Pulse Valve Diaphragms:

Diaphragm For BFEC DMF-Z-50S DMF-Y-50S 2'' Pulse Valve Repair Kit

More BFEC Pulse Valve For You to Choose:

Diaphragm For BFEC DMF-Z-50S DMF-Y-50S 2'' Pulse Valve Repair KitDiaphragm For BFEC DMF-Z-50S DMF-Y-50S 2'' Pulse Valve Repair KitDiaphragm For BFEC DMF-Z-50S DMF-Y-50S 2'' Pulse Valve Repair Kit

Right Angle Type Quick Mount Type Submerged Type

Diaphragm For BFEC DMF-Z-50S DMF-Y-50S 2'' Pulse Valve Repair Kit Diaphragm For BFEC DMF-Z-50S DMF-Y-50S 2'' Pulse Valve Repair Kit Diaphragm For BFEC DMF-Z-50S DMF-Y-50S 2'' Pulse Valve Repair Kit

Solenoid Coil Armature Assembly Pulse Controller

Focus on your demands, Offer you best solution:

√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing

Welcome to your any question and inquiry!
