AirTAC Type 4V320-08 1/4'' 5 Way 2 Position Pneumatic Air Valve
AirTAC Type 4V320-08 1/4'' 5 Way 2 Position Pneumatic Air Valve
Specifications
Brand Name :
Brando
Model Number :
4V320-08
Certification :
CE
Place of Origin :
China
MOQ :
100 PCS
Payment Terms :
T/T, PayPal, Western Union
Supply Ability :
100000 pcs per month
Delivery Time :
Negotiation
Packaging Details :
inner boxes,cartons,pallets
Port Size :
In=Out=Exhaust=1/4''
Valve Type :
Double solenoid 5 port 2 position
Voltage :
220VAC 110VAC 24VDC 12VDC
Connector :
Terminal & Grommet
Working Pressure :
0.15 to 0.8MPa(21-114psi)
Temperature :
-20 to +70℃
Max. frequency :
5 cycle/sec
Body Material :
Aluminum alloy
Fluid :
Air (to be filtered by 40 μm filter element)
Application :
Automation
Price :
Negotiation
Description

AirTAC Type 4V320-08 1/4'' 5 Way 2 Position Pneumatic Air Valve

Application Field & Working Principle of 4V series 5/2 Way Pneumatic Solenoid Valve:

5/2 or 5/3 way AirTAC type pneumatic solenoid valves are used to control the flow of the compressed air with 12V DC, 24V DC, 110V AC and 220V AC, and widely applied in the industrial fields like chemical, petroleum, pharmaceutical, automotive, light industry, food, mineral processing, electroplating, metallurgy, textiles etc.

The pilot-operated two-position four-way or five-way (4/2-way or 5/2-way) solenoid valve pushes the valve stem in the valve by the intake pressure from the pilot hole to realize the gas (liquid) reversing function. Pilot-operated 4/2-way or 5/2-way solenoid valves are general purpose for both air and liquid due to different structure and sealing form.

Technical Data:

Model
4V310-08
4V320-08
4V330C-08
4V330E-08
4V330P-08
4V310-10
4V320-10
4V330C-10
4V330E-10
4V330P-10
Fluid
Air(to be filtered by 40 μ m filter element)
Acting
Internal pilot or external pilot
Port Size
In=Out=Exhaust=1/4''
In=Out=3/8'' Exhaust=1/4''
Orifice Size
25.00 mm2 (Cv=1.40)
18.00 mm2 (Cv=1.00)
30.00 mm2 (Cv=1.68)
18.00 mm2 (Cv=1.00)
Valve Type
5 port 2 position
5 port 3 position
5 port 2 position
5 port 3 position
Operating Pressure
0.15~0.8MPa(21~114psi)
Proof Pressure
1.5MPa(215psi)
Temperature ℃
-20~70
Material of Body
Aluminum alloy
Max. frequency
4 cycle/sec
4 cycle/sec
4 cycle/sec
4 cycle/sec

Dimension Diagram:

AirTAC Type 4V320-08 1/4'' 5 Way 2 Position Pneumatic Air Valve

4V320(Grommet)

AirTAC Type 4V320-08 1/4'' 5 Way 2 Position Pneumatic Air Valve

4V320(Terminal)

Product Features:
1. High-strength aluminum alloy botton cover
2. One-time machining of valve lever by CNC, high precision
3. Valve body was machining by CNC, clean and beautifull
4. spacial processing of inner hole, small friction resistance and low starting pressure
5. High-precision pilot accessories, excitation time of only 0.05 seconds
6. imported seals, the life up to 10 millions of times
7. Aluminum alloy piston is not easy to damage
8. Embedded copper nut not easy to loose
9. with a manual device for installaton and testing
10. Copper coil has avariety of voltage available for selection

Brando Supply:
1.Solenoid Valve:
Pulse Jet Valve: Goyen Type Pulse Jet Valve, SBFEC Type Pulse Jet Valve, ASCO Type Pulse Jet Valve , Turbo Type Pulse Jet Valve.
Direct Acting Solenoid Valve:Brass Solenoid Valve, Stainless Steel Solenoid Valve, Plastic Solenoid Valve and etc.
Refrigeration Solenoid Valve:Castel Type Solenoid Valve, Danfoss Type Solenoid Valve.

2.Repair Kit:Solenoid Coil, Solenoid Armature/Stem, Diaphragm Repair Kit and etc.

Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing

Welcome to your any question and inquiry!
