230V AC 113-030-0032 113-030-0050 Nass Type System 13 Magnetic Coil
230V AC 113-030-0032 113-030-0050 Nass Type System 13 Magnetic Coil
Specifications
Brand Name :
BRANDO
Model Number :
BB14542004
Certification :
None
Place of Origin :
Ningbo, China
MOQ :
1000
Price :
Negotiation
Payment Terms :
T/T, PayPal, Western Union
Supply Ability :
250000 sets per month
Delivery Time :
Negotiation
Packaging Details :
Inner boxes, carton, pallet
Type :
Electronic drain valve accessories
Material :
BMC, Brass
Product name :
Solenoid Coils
Voltage :
DC12V/DC24V/AC110V/AC220V
Dimension(Hole x Width x Height) :
14mm x 29mm x 42mm
Power :
Solenoid Control
Color :
Black (Other color can be customized)
Application :
TM30 Electronic Drain Valve Automatic Control
Insulation class :
H
Connection type :
DIN43650B
Description

230V AC 113-030-0032 113-030-0050 Nass Type System 13 Magnetic Coil

Features:

1. Product Name: Nass Magnet Replacement Solenoid Coil
2. Voltages: 12VDC, 24VDC, 24VAC, 110VAC, 120VAC, 220VAC, 230VAC, 240VAC (50/60Hz)
3. Power: 22VA, 13W, 20W
4. Connector: DIN 43650 Form A Plug
5. Insulation Class: Class H, Class, F
6. Protection Class: IP65
7. Application Examples: Auto Drain Valve, Shako Solenoid Valve, such like PU220, PU225, SPU225, etc.

Technical parameter of electronic drain valve solenoid coils:

Code No Voltage

Frequency

(Hz)
Power
W/VA
113-030-0042 24VDC 2,0
113-030-0045 48VDC 2,1
113-030-0032 48VDC 1,6
113-030-0032 220VAC 50 6,4
113-030-0032 230VAC 50 6,6
113-030-0032 240VAC 50 5,7
113-030-0278 12VDC 6,0
113-030-0026 24VDC 6,1
113-030-0029 24VAC 50 10,8
113-030-0029 24VAC 60 9,6
113-030-0036 110VAC 50 11,1
113-030-0036 120VAC 60 11,7
113-030-0033 220VAC 50 10,8
113-030-0044 12VAC 50 19,3
113-030-0044 12VAC 50 17,1
113-030-0027 24VDC 11,0
113-030-0039 24VAC 50 17,9
113-030-0039 24VAC 60 15,6
113-030-0037 110VAC 50 17,6
113-030-0037 120VAC 50 18,3
113-030-0034 220VAC 50 18,1
113-030-0034 240VAC 60 18,9
113-030-0033 240VAC 50 11,4
113-030-0047 12VDC 15,0
113-030-0028 24VDC 15,0
113-030-0040 24VAC 50 21,8,
113-030-0040 24VAC 50 19.4
113-030-0043 48VAC 50 26,2
113-030-0043 48VAC 50 23,2
113-030-0052 48VAC 50 19,0
113-030-0052 48VAC 50 16,6
113-030-0038 110VAC 50 24,8
113-030-0049 110VAC 50 21,7
113-030-0049 110VAC 50 19,2
113-030-0038 120VAC 50 26,1
113-030-0041 195VDC 16,6
113-030-0035 220VAC 50 22,0
113-030-0050 230vAC 50 21,4
113-030-0050 230VAC 50 19,0
113-030-0031 240VAC 50 17,9
113-030-0035 240VAC 50 23,2


Main dimension of 5043/5045 solenoid coils for water electronic drain valve:

230V AC 113-030-0032 113-030-0050 Nass Type System 13 Magnetic Coil

Detail enlargement of 14 mm Inside Hole 42 High electric solenoid coils:

230V AC 113-030-0032 113-030-0050 Nass Type System 13 Magnetic Coil

Connection of AC220V/DC24V black electromagnetic coils in electronic drain valve:

230V AC 113-030-0032 113-030-0050 Nass Type System 13 Magnetic Coil

Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing

Welcome to your inquiry!
