700 bar 10000 PSI High Pressure Solenoid Valve 1/8'' 1/4'' 220V 110V 24V 12V
700 bar 10000 PSI High Pressure Solenoid Valve 1/8'' 1/4'' 220V 110V 24V 12V
Specifications
Brand Name :
BRANDO
Model Number :
H4S005B01, H4S005B02
Certification :
CE, ISO
Place of Origin :
Ningbo, China
MOQ :
4pcs
Price :
Negotiation
Payment Terms :
T/T, PayPal, Western Union
Supply Ability :
50000pcs per month
Delivery Time :
4 to 7 working days
Packaging Details :
Box, Carton, Pallet
Product Name :
High Pressure Solenoid Valve
Port Size :
1/8'',1/4''
Thread Type :
G, NPT
Connection Type :
Female Threaded
Orifice Size :
0.5mm
Body Material :
Stainless Steel 316
Seal Material :
PEEK, PCTFE
Working Medium :
Water, Air, Gas, Liquid, etc
Max Working Pressure :
700 bar
Operation :
Direct Acting
Function :
2 Way Normally Closed
Voltage :
12VDC, 24VDC, 24VAC, 110VAC, 220VAC
Description

700 bar 10000 PSI High Pressure Solenoid Valve 1/8'' 1/4'' 220V 110V 24V 12V

Product Features:

1. Working Medium: Water, Air, Gas, Liquid, etc
2. Working Pressure: 0 to 700 bar
3. Body Material: Stainless Steel 316
4. Seal Material: PEEK, PTCFE
5. Port Size: 1/8'', 1/4''
6. Orifice Size: 0.5mm
7. Function: 2 Way Normally Closed
8. Operation: Direct Acting
9. Voltage: 12VDC, 24VDC, 24VAC, 110VAC, 220VAC (50/60Hz)

Technical Data:

Model No
Port Size
Orifice Size
Cv
Working Pressure
Body
Seal
Function
Voltage
H4S005B01
1/8''
0.5mm
0.02
0 to 700 bar
SS316
PEEK
PCTFE
2 Way NC
12VDC
24VDC
24VAC
110VAC
220VAC
H4S005B02
1/4''
0.5mm
0.02
0 to 700 bar

Main Dimension:

700 bar 10000 PSI High Pressure Solenoid Valve 1/8'' 1/4'' 220V 110V 24V 12V

Our Production:

700 bar 10000 PSI High Pressure Solenoid Valve 1/8'' 1/4'' 220V 110V 24V 12V

FAQ:

Question 1: What is a solenoid valve used for?
Answer 1: A solenoid valve is used to open, close, mix, or divert media in an application. They are used in a wide variety of applications.

Question 2: How can you tell if your solenoid valve is bad?
Answer 2: If the solenoid valve fails to open or close, is partially open, makes a humming noise or has a burned-out solenoid coil, you need to troubleshoot the valve solenoids.

Question 3: How do I choose a solenoid valve?
Answer 3: When choosing a solenoid valve, it is important to know your media. Depending upon the media and flow requirement, choose the material, port size, orifice size, temperature, pressure, voltage, response time and certification required for your application.

Similar Products:

700 bar 10000 PSI High Pressure Solenoid Valve 1/8'' 1/4'' 220V 110V 24V 12V 700 bar 10000 PSI High Pressure Solenoid Valve 1/8'' 1/4'' 220V 110V 24V 12V 700 bar 10000 PSI High Pressure Solenoid Valve 1/8'' 1/4'' 220V 110V 24V 12V 700 bar 10000 PSI High Pressure Solenoid Valve 1/8'' 1/4'' 220V 110V 24V 12V
Max 300 bar Max 350 bar Max 360 bar Max 360 bar

Focus on your demands, Offer you best solution:

√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing

Welcome to your any question and inquiry!
