190 bar High Pressure Water Air Stainless Steel Solenoid Valve 1/8'' 1/4'' 3/8'' 220V 110V
190 bar High Pressure Water Air Stainless Steel Solenoid Valve 1/8'' 1/4'' 3/8'' 220V 110V
Specifications
Brand Name :
BRANDO
Model Number :
H9S
Certification :
CE, ISO
Place of Origin :
Ningbo, China
MOQ :
4pcs
Price :
Negotiation
Payment Terms :
T/T, PayPal, Western Union
Supply Ability :
10000pcs per month
Delivery Time :
7 working days
Packaging Details :
Box, Carton, Pallet
Product Name :
High Pressure Solenoid Valve
Port Size :
1/8'', 1/4'', 3/8''
Thread Type :
G, NPT
Orifice Size :
1.5mm, 2mm, 2.5mm, 3mm, 4mm
Body Material :
Stainless Steel 304, Stainless Steel 316
Seal Material :
NBR, EPDM, FKM
Working Media :
Air, Water, Gas, Liquid, Light Oil, etc
Max Working Pressure :
190 bar
Operation :
Direct Acting
Function :
2 Way Normally Closed
Voltage :
220VAC, 110VAC, 24VAC, 24VDC, 12VDC
Description

190 bar High Pressure Water Air Stainless Steel Solenoid Valve 1/8'' 1/4'' 3/8'' 220V 110V

Product Features:

1. Working Medium: Water, Air, Gas, Oil, Liquid, etc
2. Medium Temperature: NBR (-5 to +80ºC), EPDM (-5 to +120ºC), FKM (-10 to +150ºC)
3. Max Working Pressure: 190 bar
4. Body Material: SS304, SS316
5. Seal Material: NBR, EPDM, FKM
6. Port Size: 1/8'', 1/4'', 3/8''
7. Orifice Size: 1.5mm, 2mm, 2.5mm, 3mm, 4mm
8. Function: 2 Way Normally Closed
9. Operation: Direct Acting
10. Voltage: 12VDC, 24VDC, 24VAC, 110VAC, 220VAC (50/60Hz)

Technical Data:

Model No
Port
Orifice
CV
Min Pressure
(bar)
Max Pressure
(bar)
Body
Seal
Function
AC
DC
H9S015B01
1/8''
1.5mm
0.08
0
190
170
SS304
SS316
NBR
EPDM
FKM
2 Way NC
H9S020B01
2mm
0.14
120
100
H9S025B01
2.5mm
0.23
80
80
H9S030B01
3mm
0.25
50
50
H9S015B02
1/4''
1.5mm
0.08
190
170
H9S020B02
2mm
0.14
120
100
H9S025B02
2.5mm
0.23
80
80
H9S030B02
3mm
0.25
50
50
H9S030B03
3/8''
3mm
0.25
50
50
H9S040B03
4mm
0.6
30
24

Main Dimension:

190 bar High Pressure Water Air Stainless Steel Solenoid Valve 1/8'' 1/4'' 3/8'' 220V 110V

Our Production:

190 bar High Pressure Water Air Stainless Steel Solenoid Valve 1/8'' 1/4'' 3/8'' 220V 110V

FAQ:

Question 1: What is a solenoid valve used for?
Answer 1: A solenoid valve is used to open, close, mix, or divert media in an application. They are used in a wide variety of
applications.

Question 2: How can you tell if your solenoid valve is bad?
Answer 2: If the solenoid valve fails to open or close, is partially open, makes a humming noise or has a burned-out solenoid coil, you need to troubleshoot the valve solenoids.

Question 3: How do I choose a solenoid valve?
Answer 3: When choosing a solenoid valve, it is important to know your media. Depending upon the media and flow requirement, choose the material, port size, orifice size, temperature, pressure, voltage, response time and certification required for your application.

Similar Valves:

190 bar High Pressure Water Air Stainless Steel Solenoid Valve 1/8'' 1/4'' 3/8'' 220V 110V 190 bar High Pressure Water Air Stainless Steel Solenoid Valve 1/8'' 1/4'' 3/8'' 220V 110V 190 bar High Pressure Water Air Stainless Steel Solenoid Valve 1/8'' 1/4'' 3/8'' 220V 110V 190 bar High Pressure Water Air Stainless Steel Solenoid Valve 1/8'' 1/4'' 3/8'' 220V 110V
Max 200 bar Max 200 bar Max 300 bar Max 360 bar

Focus on your demands, Offer you best solution:

√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing

Welcome to your any question and inquiry!
