Round Stainless Steel Mini Air Cylinder CRDSW Type With Bore 32 - 63mm
Round Stainless Steel Mini Air Cylinder CRDSW Type With Bore 32 - 63mm
Round Stainless Steel Mini Air Cylinder CRDSW Type With Bore 32 - 63mm
Round Stainless Steel Mini Air Cylinder CRDSW Type With Bore 32 - 63mm
Specifications
Brand Name :
PRIUS,XINYI or OEM
Model Number :
CRDSW
Place of Origin :
Ningbo,China
MOQ :
5pcs
Price :
negotiation
Payment Terms :
T/T, L/C, Western Union,Paypal
Supply Ability :
20000pcs per month
Delivery Time :
10~15 working days
Packaging Details :
bag+box+catons+pallet
name :
stainless steel air cylinder
Working Medium :
Air
Working Pressure :
1-9.0Kgf/cm²
Pressure :
13.50Kgf/cm²
Temperature Range :
0-70℃
Speed Range :
50~800mm/s
Buffer Type :
Gasket Buffer/Adjustable Buffer
Port Size :
G1/8" ~ G3/8"
Fix Type :
Normal/LB/FA/FB/SDB
Motion Pattern :
Single/Double acting
Description

Round Stainless Steel Mini Air Cylinder CRDSW Type With Bore 32 - 63mm

Quick Detail:

* CRDSW type Round Stainless Steel Pneumatic Mini Cylinder

* With magnet,air buffer adjustable or rubber cushion for choice

* Stainless steel barrel,Aluminum tube can be optional

* Piston rod #45(ASTM-1045) steel chrome-plated

* Stainless steel piston rod is available

* With guide plate type available

* With self-lubricating bearing,lubrication free

* Bore size 32mm,40mm,50mm,63mm

* Cylinder kits and accessories available

Specifiction

Bore (mm) 32 40 50 63
Motion Pattern Double Acting or Single Acting
Working Medium Air
Fixed Type Normal Type/ LB Type/ FA Type/ SDB Type
Working Pressure Range 1~9.0MPa
Ensured Pressure Resistance 13.5MPa
Operating Temperature Range 0~70℃
Operating Speed Range 50~800mm/s
Buffer Type Gasket Buffer / Adjustable Buffer
Port Size G1/8″ G1/4" G3/8″

Stroke

Bore(mm) Stroke Max.Stroke Permissible Stroke
32 1…500 500 800
40 1000
50 1200
60 1500

Round Stainless Steel Mini Air Cylinder CRDSW Type With Bore 32 - 63mm

Round Stainless Steel Mini Air Cylinder CRDSW Type With Bore 32 - 63mmRound Stainless Steel Mini Air Cylinder CRDSW Type With Bore 32 - 63mmRound Stainless Steel Mini Air Cylinder CRDSW Type With Bore 32 - 63mmRound Stainless Steel Mini Air Cylinder CRDSW Type With Bore 32 - 63mm
