IMI Norgren RA/8040/M/125 RA/8040/M/160 RA/8040/M/200 RA/8040/M/250 Double-Acting Cylinder
IMI Norgren RA/8040/M/125 RA/8040/M/160 RA/8040/M/200 RA/8040/M/250 Double-Acting Cylinder
IMI Norgren RA/8040/M/125 RA/8040/M/160 RA/8040/M/200 RA/8040/M/250 Double-Acting Cylinder
IMI Norgren RA/8040/M/125 RA/8040/M/160 RA/8040/M/200 RA/8040/M/250 Double-Acting Cylinder
Specifications
Brand Name :
IMI Norgren, AIRWOLF or OEM
Model Number :
RA/8040/M/125, RA/8040/M/160, RA/8040/M/200, RA/8040/M/250
Certification :
CE, ISO9001
Place of Origin :
UK, China
MOQ :
1 piece
Price :
10-186USD
Payment Terms :
T/T,Western Union,Paypal
Supply Ability :
1000 pcs per week
Delivery Time :
1-7 work days
Packaging Details :
Boxes, Cartons, Pallets, Plastic bags
Item Code :
RA/8040/M/125, RA/8040/M/160, RA/8040/M/200, RA/8040/M/250
Barrel Material :
Anodised aluminium
Piston Rod Material :
Stainless steel
Working Pressure :
1~16 bar
Operating temperature :
-10~+80℃
Bore Size :
40mm
Stroke :
125, 160, 200, 250mm
Feature :
Double acting, adjustable cushioning
Description
IMI Norgren RA/8040/M/125 RA/8040/M/160 RA/8040/M/200 RA/8040/M/250 Double-Acting Cylinder
The IMI Norgren RA/8000/M Series excels in diverse industrial environments, particularly in robotic arms, picking and packing systems, lifts and hoists, and clamping machinery. Its wide operating temperature range from -10°C to +80°C allows it to function effectively in harsh conditions, while the magnetic piston design enables easy integration with proximity switches for precise position tracking. The cylinders are commonly used in food processing, automotive manufacturing, aerospace industries, and packaging plants where consistent linear motion is essential.

Order Codes:
Item Code Bore Size (ø mm) Stroke (mm) Type
RA/8040/M/125 40 125 Round barrel
RA/8040/M/160 40 160 Round barrel
RA/8040/M/200 40 200 Round barrel
RA/8040/M/250 40 250 Round barrel
Datasheet:
Cylinder ø (mm) 32 40 50 63 80 100 125 160 200 250 320
Profile barrel ● ● ● ● ● ● ●



Round barrel ● ● ● ● ● ● ● ● ● ● ●
Port size G1/8 G1/4 G1/4 G3/8 G3/8 G1/2 G1/2 G3/4 G3/4 G1 G1
Piston rod ø (mm) 12 16 20 20 25 25 32 40 40 50 63
Piston rod thread M10 x 1,25 M12 x 1,25 M16 x 1,5 M16 x 1,5 M20 x 1,5 M20 x 1,5 M27 x 2 M36 x 2 M36 x 2 M42 x 2 M48 x 2
Cushion length (mm) 20 22 24 24 26 33 39 43 43 55 60
Cushioning
Adaptive cushioning systems "ACS"		 ● ● ● ● ● ● ●



Cushioning (adjustable cushion)






● ● ● ●
Initial cushion volume (cm3) 12,8 20,2 36 64 111 235 427 784 1273 2534 4559
Theoretical thrusts at 6 bar outstroke (N) 482 754 1178 1870 3016 4710 7363 12064 18840 29436 48228
Theoretical thrusts at 6 bar instroke (N) 414 633 990 1680 2722 4416 6882 11310 18090 28236 47292
Air consumption at 6 bar outstroke (l/cm) 0,056 0,088 0,137 0,218 0,35 0,55 0,86 1,41 2,2 3,44 5,63
Air consumption at 6 bar instroke (l/cm) 0,048 0,074 0,114 0,195 0,32 0,51 0,79 1,32 2,1 3,3 5,41

Dimensions:
IMI Norgren RA/8040/M/125 RA/8040/M/160 RA/8040/M/200 RA/8040/M/250 Double-Acting CylinderIMI Norgren RA/8040/M/125 RA/8040/M/160 RA/8040/M/200 RA/8040/M/250 Double-Acting Cylinder* Please insert stroke length.
