5/3 Closed Pneumatic Solenoid Valves VSVA-B-P53C-H-A1-1C1 546708 GTIN4052568184919
5/3 Closed Pneumatic Solenoid Valves VSVA-B-P53C-H-A1-1C1 546708 GTIN4052568184919
5/3 Closed Pneumatic Solenoid Valves VSVA-B-P53C-H-A1-1C1 546708 GTIN4052568184919
5/3 Closed Pneumatic Solenoid Valves VSVA-B-P53C-H-A1-1C1 546708 GTIN4052568184919
Specifications
Brand Name :
FESTO
Model Number :
VSVA-B-P53C-H-A1-1C1
Place of Origin :
China
MOQ :
1pc
Price :
EXW USD100-150
Payment Terms :
T/T, Western Union, Paypal
Supply Ability :
1000pcs per month
Delivery Time :
7-10 working days
Packaging Details :
Plastic bag, Carton
Model :
VSVA-B-P53C-H-A1-1C1
Order no :
546708
Brand :
FESTO
Valve function :
5/3 closed
Nominal size :
9 mm
Sealing principle :
Soft
Description

FESTO Solenoid valve VSVA-B-P53C-H-A1-1C1 546708 GTIN4052568184919

About product

1.Valves can be replaced under pressure using a vertical pressure shut-off plate.

2.Wide range of valve functions.

3.Vertical supply plates permit a flexible air supply and variable pressure zones.

Technical Data

Valve function 5/3 closed
Type of actuation Electric
Valve size 26 mm
Operating voltage 24V DC
Approval c UL us - Recognized (OL)
Degree of protection IP65 NEMA 4
Nominal size 9 mm
Exhaust-air function With flow control option
Sealing principle Soft
Mounting position optional
Conforms to standard ISO 15407-1 VDMA 24563
Manual override Non-detenting
Type of piloting Pilot actuated
Pilot air supply Internal
Flow direction Non-reversible
Symbol 00991080
lap Positive overlap
Signal status display LED
Corrosion resistance class CRC 0 - No corrosion stress
LABS (PWIS) conformity VDMA24364-B1/B2-L
Product weight 305 g
Type of mounting On sub-base
Note on materials RoHS-compliant
Material seals HNBR NBR
Material housing Die-cast aluminium
Material screws Steel Galvanised

About product

5/3 Closed Pneumatic Solenoid Valves VSVA-B-P53C-H-A1-1C1 546708 GTIN4052568184919

There are many models and types, welcome to enquiry!
