FESTO Pneumatic Solenoid Valves VUVG-B14-M52-AZT-F-1T1L 573482 GTIN4052568102760
FESTO Pneumatic Solenoid Valves VUVG-B14-M52-AZT-F-1T1L 573482 GTIN4052568102760
FESTO Pneumatic Solenoid Valves VUVG-B14-M52-AZT-F-1T1L 573482 GTIN4052568102760
FESTO Pneumatic Solenoid Valves VUVG-B14-M52-AZT-F-1T1L 573482 GTIN4052568102760
FESTO Pneumatic Solenoid Valves VUVG-B14-M52-AZT-F-1T1L 573482 GTIN4052568102760
FESTO Pneumatic Solenoid Valves VUVG-B14-M52-AZT-F-1T1L 573482 GTIN4052568102760
Specifications
Brand Name :
FESTO
Model Number :
VUVG-B14-M52-AZT-F-1T1L
Place of Origin :
China
MOQ :
1pc
Price :
EXW USD60-80
Payment Terms :
T/T, Western Union, Paypal
Supply Ability :
100 pcs per month
Delivery Time :
7-10 working days
Packaging Details :
Plastic bag, Carton
Order no :
573482
Model :
VUVG-B14-M52-AZT-F-1T1L
Brand :
FESTO
Operating voltage :
24V DC
Valve function :
5/2-way, monostable
Degree of protection :
IP65 IP67
Description

FESTO Solenoid valve VUVG-B14-M52-AZT-F-1T1L 573482 GTIN4052568102760 Pneumatic Solenoid Valves

About product
1.Reduced power consumption.

2.Excellent price/performance ratio.

3.Choice of quick push-in connectors.

4.Multiple pressure zones possible.

Technical Data

Valve function 5/2-way, monostable
Type of actuation Electric
Valve size 14 mm
Standard nominal flow rate 500 l/min
pneumatic working port Flange
Operating voltage 24V DC
Design Piston gate valve
Type of reset Pneumatic spring
Approval c UL us - Recognized (OL)
Degree of protection IP65 IP67
Exhaust-air function With flow control option
Sealing principle Soft
Mounting position optional
Manual override Detenting Non-detenting
Type of piloting Pilot actuated
Pilot air supply External
Flow direction Reversible
Symbol 00991053
lap Positive overlap
Signal status display LED
Max. switching frequency 3 Hz
Switching time off 26 ms
Switching time on 13 ms
Duty cycle 100%
Characteristic coil data 22 V DC: 1.0 W
Operating medium Compressed air to ISO 8573-1:2010 [7:4:4]
Corrosion resistance class CRC 2 - Moderate corrosion stress
LABS (PWIS) conformity VDMA24364-B1/B2-L
Media temperature -5°C-60°C
Pilot medium Compressed air to ISO 8573-1:2010 [7:4:4]
Ambient temperature -5°C-60°C
Product weight 91 g
Electrical connection Via sub-base
Type of mounting On manifold rail
Note on materials RoHS-compliant
Material seals HNBR NBR
Material housing Wrought aluminium alloy

Another Size as below,

Type Order no Price
VUVG-B14-T32C-AZT-F-1T1L 573476 USD60-80
VUVG-B14-T32U-AZT-F-1T1L 573477 USD60-80
VUVG-B14-T32H-AZT-F-1T1L 573478 USD60-80
VUVG-B14-T32C-MZT-F-1T1L 573479 USD60-80
VUVG-B14-T32U-MZT-F-1T1L 573480 USD60-80
VUVG-B14-T32H-MZT-F-1T1L 573481 USD60-80
VUVG-B14-M52-AZT-F-1T1L 573482 USD60-80
VUVG-B14-M52-MZT-F-1T1L 573483 USD60-80
VUVG-B14-B52-ZT-F-1T1L 573484 USD60-80
VUVG-B14-P53C-ZT-F-1T1L 573485 USD60-80
VUVG-B14-P53U-ZT-F-1T1L 573487 USD60-80
VUVG-B14-P53E-ZT-F-1T1L 573486 USD60-80
FESTO Pneumatic Solenoid Valves VUVG-B14-M52-AZT-F-1T1L 573482 GTIN4052568102760

There are so many products, welcome to enquire!
