FESTO Pneumatic Air Cylinders Silencer AMTE-M-LH-G18 1205860 GTIN4052568061593
FESTO Pneumatic Air Cylinders Silencer AMTE-M-LH-G18 1205860 GTIN4052568061593
FESTO Pneumatic Air Cylinders Silencer AMTE-M-LH-G18 1205860 GTIN4052568061593
FESTO Pneumatic Air Cylinders Silencer AMTE-M-LH-G18 1205860 GTIN4052568061593
FESTO Pneumatic Air Cylinders Silencer AMTE-M-LH-G18 1205860 GTIN4052568061593
FESTO Pneumatic Air Cylinders Silencer AMTE-M-LH-G18 1205860 GTIN4052568061593
Specifications
Brand Name :
FESTO
Model Number :
AMTE-M-LH-G18
Place of Origin :
China
MOQ :
1 PC
Price :
EXW USD2-3
Payment Terms :
T/T, Western Union, Paypal
Supply Ability :
1000 PCS per month
Delivery Time :
5-7working days
Packaging Details :
plastic bag, carton
Order no :
1205860
Specifications :
AMTE-M-LH-G18
Brand :
FESTO
Size of pack :
20
Note on materials :
RoHS-compliant
Weight :
7.5 g
Description

FESTO Silencer AMTE-M-LH-G18 1205860 GTIN4052568061593

About product

1.Long design.

2.Metal version.

3.Operating medium compressed air.

4.Suitable for reducing noise at the exhaust ports of pneumatic systems.

5.Material screw-in stud:brass

Technical Data

Mounting position optional
Size of pack 20
Symbol 00991473
Operating pressure 0 MPa ... 1 MPa
Operating pressure 0 bar ... 10 bar
Flow rate to atmosphere 1735 l/min
Operating medium Compressed air to ISO 8573-1:2010 [7:-:-]
Note on operating and pilot medium Lubricated operation possible
Corrosion resistance class CRC 1 - Low corrosion stress
LABS (PWIS) conformity VDMA24364-B1/B2-L
Sound pressure level 76 dB(A)
Ambient temperature -40°C-80°C
Product weight 7.5 g
Pneumatic connection G1/8
Material shock absorber insert Bronze
Material screw-in stud Brass
Note on materials RoHS-compliant

Other size as below

ORDER NO TYPE
1231120 AMTE-M-LH-M3
1205858 AMTE-M-LH-M5
1205860 AMTE-M-LH-G18
1205861 AMTE-M-LH-G14
1205862 AMTE-M-LH-G38
1205863 AMTE-M-LH-G12
1205864 AMTE-M-LH-G34
1205865 AMTE-M-LH-G1

Dimensions

FESTO Pneumatic Air Cylinders Silencer AMTE-M-LH-G18 1205860 GTIN4052568061593

After-sale Service
We can provide a series of after-sale service, such as product introduction, mounting, debugging, technical support and so on.
There are many models,please hurry to me!
