Die Cast Zinc Festo Filter LF-D-5M-MIDI-A 192561 GTIN4052568152307
Die Cast Zinc Festo Filter LF-D-5M-MIDI-A 192561 GTIN4052568152307
Die Cast Zinc Festo Filter LF-D-5M-MIDI-A 192561 GTIN4052568152307
Die Cast Zinc Festo Filter LF-D-5M-MIDI-A 192561 GTIN4052568152307
Specifications
Brand Name :
FESTO
Model Number :
LF-D-5M-MIDI-A
Place of Origin :
China
MOQ :
1pc
Price :
EXW USD50-60
Payment Terms :
T/T, Western Union, Paypal
Supply Ability :
1000 pcs per month
Delivery Time :
7-10working days
Packaging Details :
Plastic bag, Carton
Type :
LF-D-5M-MIDI-A
Part no :
192561
Brand :
FESTO
Weight :
700 g
Media temperature :
5°C-60°C
Material housing :
Die-cast zinc
Description

FESTO Filter LF-D-5M-MIDI-A 192561 GTIN4052568152307

About product

1.Good particle and condensate separation.

2.High flow rate with minimal pressure drop.

3.With or without connecting plates.

4.With manual or fully automatic condensate drain.

Technical Data

Size Midi
Series D
Condensate drain Fully automatic
Design Sintered filter with centrifugal separator
Max. condensate volume 43 ml
Bowl guard Metal bowl guard
Symbol 00991520
Operating pressure 2 bar ... 12 bar
Operating medium Compressed air to ISO 8573-1:2010 [7:9:-] Inert gases
Corrosion resistance class CRC 2 - Moderate corrosion stress
LABS (PWIS) conformity VDMA24364-B1/B2-L
Storage temperature -10°C-60°C
Air purity class at output Compressed air to ISO 8573-1:2010 [6:8:4] Inert gases
Media temperature 5°C-60°C
Ambient temperature 5°C-60°C
Product weight 700 g
Type of mounting In-line installation With accessories
Pneumatic connection, port 1 Sub-base
Pneumatic connection, port 2 Sub-base
Note on materials RoHS-compliant
Material filter PE
Material housing Die-cast zinc
Material bowl PC

Peripherals overview

Die Cast Zinc Festo Filter LF-D-5M-MIDI-A 192561 GTIN4052568152307
