FESTO Compact Pneumatic Air Cylinders ADVU-63-20 -P-A-S2 156017
FESTO Compact Pneumatic Air Cylinders ADVU-63-20 -P-A-S2 156017
FESTO Compact Pneumatic Air Cylinders ADVU-63-20 -P-A-S2 156017
FESTO Compact Pneumatic Air Cylinders ADVU-63-20 -P-A-S2 156017
FESTO Compact Pneumatic Air Cylinders ADVU-63-20 -P-A-S2 156017
FESTO Compact Pneumatic Air Cylinders ADVU-63-20 -P-A-S2 156017
Specifications
Brand Name :
FESTO
Model Number :
ADVU-63-20 -P-A-S2
Place of Origin :
China
MOQ :
1pc
Price :
EXW USD50-80
Payment Terms :
T/T, Western Union, Paypal
Supply Ability :
50 pcs per month
Delivery Time :
10-12 working days
Packaging Details :
plastic bag, carton，OPP bag
Part no :
156017
Type :
ADVU-63-20 -P-A-S2
Brand :
FESTO
Stroke :
20 mm
Piston diameter :
63 mm
Mode of operation :
Double-acting
Description

FESTO Compact cylinder,ADVU-63-20 -P-A-S2 156017

About product

Symbol:'00991219

Corrosion resistance class CRC:2 - Moderate corrosion stress

Pneumatic connection:G1/8

Technical Data

Stroke 20 mm
Piston diameter 63 mm
Cushioning Elastic cushioning rings/plates at both ends
Mounting position optional
Mode of operation Double-acting
Piston-rod end Female thread
Design Piston Piston rod
Position detection Via proximity switch
Symbol 00991219
Variants Through piston rod
Corrosion resistance class CRC 2 - Moderate corrosion stress
LABS (PWIS) conformity VDMA24364-B1/B2-L
Ambient temperature -20°C-80°C
Pneumatic connection G1/8
Material collar screws Galvanised steel
Material cover Wrought aluminium alloy
Material dynamic seals NBR TPE-U(PU)
Material piston rod High-alloy steel
Material cylinder barrel Wrought aluminium alloy

Product range overview

FESTO Compact Pneumatic Air Cylinders ADVU-63-20 -P-A-S2 156017
