PLC Control Robotic Bag Unloading Equipment System For Plastic
PLC Control Robotic Bag Unloading Equipment System For Plastic
PLC Control Robotic Bag Unloading Equipment System For Plastic
PLC Control Robotic Bag Unloading Equipment System For Plastic
PLC Control Robotic Bag Unloading Equipment System For Plastic
PLC Control Robotic Bag Unloading Equipment System For Plastic
Specifications
Brand Name :
MACHTECH
Certification :
CE ISO
Place of Origin :
China
Capacity :
Depends on the specific system and customer needs
Control System :
PLC
Installation :
On-site installation by professional technicians
Safety Features :
Emergency Stop Button, Safety Interlock System
Material :
Stainless Steel
Operation Mode :
Automatic
Power Source :
Electricity
Product Type :
Industrial Equipment
Loading Method :
Pneumatic or mechanical
Maintenance :
Regular maintenance required for optimal performance
Unloading Method :
Gravity or pneumatic
Application :
Unloading raw materials from trucks or containers
Conveying Distance :
Customizable
Conveying Speed :
Adjustable
Dust Collection System :
Included
Installation Method :
Fixed on Ground
Unloading Mode :
Automatic
Power Supply :
380V/50Hz
Conveying Method :
Pneumatic
Description
Robotic Bag Unloading System for Plastic Industry
Key Specifications
  • Throughput : ≥300 bags/hour (2-cell system, ≥150 bags/h per unit)
  • Control System : Programmable Logic Controller (PLC)
  • Contact Surfaces : Stainless Steel 304
  • Recognition : Spherical/positional bag detection via 3D vision
  • Error Prevention : RFID/QR code verification
System Description

This dual-robot unpacking system handles plastic raw material bags with three operational modes:

  • Full-Pallet Breakdown : Layer-by-layer unloading
  • Single-Layer Separation : Selective layer removal
  • Individual Bag Processing : Isolated bag handling
Component Brands
Core Component Brand/Specification
Robotic Arm Kawasaki
Base Frame Mach Tech
3D Vision System Mech-Mind
Grippers Tool MachTech
Safety Fencing Mach Tech
Typical Applications
  • Full-pallet depalletizing
  • Selective layer removal
  • Single-bag precision pickup

Plastics Industry Applications
  • Compounding : Automated feeding of PP/PE pellets
  • Masterbatch : Additive bag unloading
  • Recycling : Post-consumer bale breakdown
Performance Notes

Throughput based on standard 25kg woven PP bags. Variables affecting speed:

  • Bag material thickness
  • Stacking pattern consistency
  • Ambient dust levels
