OEM ODM Custom 100kW Permanent Magnet Motor Generator 400V 50Hz EPMG-100CU
OEM ODM Custom 100kW Permanent Magnet Motor Generator 400V 50Hz EPMG-100CU
OEM ODM Custom 100kW Permanent Magnet Motor Generator 400V 50Hz EPMG-100CU
OEM ODM Custom 100kW Permanent Magnet Motor Generator 400V 50Hz EPMG-100CU
OEM ODM Custom 100kW Permanent Magnet Motor Generator 400V 50Hz EPMG-100CU
OEM ODM Custom 100kW Permanent Magnet Motor Generator 400V 50Hz EPMG-100CU
OEM ODM Custom 100kW Permanent Magnet Motor Generator 400V 50Hz EPMG-100CU
OEM ODM Custom 100kW Permanent Magnet Motor Generator 400V 50Hz EPMG-100CU
OEM ODM Custom 100kW Permanent Magnet Motor Generator 400V 50Hz EPMG-100CU
OEM ODM Custom 100kW Permanent Magnet Motor Generator 400V 50Hz EPMG-100CU
Specifications
Protection Grade :
IP54 to IP67
Model Number :
EPMG-100CU
Frequency :
50Hz / 60Hz Custom
Place of Origin :
China
Rated Voltage :
380V / 400V / 480V Custom
Rated Speed :
300rpm
Winding Material :
100% Pure Copper
Custom Options :
Shaft, Flange, Voltage, Frequency, Paint
Payment Terms :
L/C,T/T,Western Union,PayPal
MOQ :
1 Set
Supply Ability :
20000 Sets per Year
Delivery Time :
15-45 Days after Deposit
Price :
USD 1,000-5,000 / Set
Warranty :
2 Years
OEM / ODM :
Logo, Nameplate, Packaging, Manuals
Brand Name :
ENNENG
Cooling Method :
Air Cooled IC411
Certification :
CE, ISO 9001:2015
Phase :
Three Phase
Packaging Details :
Seaworthy plywood wooden case with foam shock-proof lining
Rated Power :
100kW
Number of Poles :
20
Description

OEM ODM Custom 100kW Permanent Magnet Motor Generator 400V 50Hz EPMG-100CU

Need a generator that matches your system, not the other way around? This 100kW OEM ODM custom permanent magnetic motor generator is built to your drawing: voltage, frequency, rotation direction, shaft extension, flange standard and even nameplate branding can be tailored, because every unit starts as a permanent magnet motor generator designed around your prime mover.

OEM ODM Custom 100kW Permanent Magnet Motor Generator 400V 50Hz EPMG-100CU

Key Features

  • Full OEM ODM service: custom shaft, flange, terminal box position and color
  • 100% pure copper winding with vacuum pressure impregnation for high reliability
  • Custom voltage from 220V to 690V and frequency 50Hz or 60Hz available
  • ISO9001 quality system with 100% routine test on every production unit
  • Small MOQ accepted for prototype evaluation, mass production within 30 days

Technical Specifications

Rated Power100kW
Rated Voltage380V / 400V / 480V Custom
PhaseThree Phase
Frequency50Hz / 60Hz Custom
Rated Speed300rpm
Number of Poles20
Winding Material100% Pure Copper
Cooling MethodAir Cooled IC411
Protection GradeIP54 to IP67
Custom OptionsShaft, Flange, Voltage, Frequency, Paint
OEM / ODMLogo, Nameplate, Packaging, Manuals
Warranty2 Years

Applications

Serving wind turbine integrators, hydro EPC contractors, genset OEMs and renewable energy distributors worldwide.

OEM ODM Custom 100kW Permanent Magnet Motor Generator 400V 50Hz EPMG-100CU

Quality & Warranty

Prototype samples supported with free engineering review. 2-year warranty, 24h technical response and spare rotor support.

ENNENG is an experienced permanent magnet motor and permanent magnetic motor generator manufacturer. Contact our sales team for quotation, OEM customization and technical support.
