Specifications
Model Number :
FE420Z
Brand Name :
SUMA
Place of Origin :
Jiangsu, China
MOQ :
10
Price :
$2-4
Precision Rating :
P6
Seals Type :
Non sealed
Type :
sprag
Material :
Chrome Steel, GCr15
Surface Hardness :
HRC60-62
Row No :
double row
Inner Diameter :
12 mm
Outer Diameter :
20 mm
Width :
12 mm
Nominal Torque :
35 Nm
Max Speed :
12,500 rpm
Weight :
0.007 kg
Structure :
FE series Freewheelclutches
Friction Direction :
One direction
Idling Direction :
Opposite direction
Description

FE 420Z Sprag Type One Way Clutch Bearing FE420Z

Product Description

Description: FE One Way Clutch Bearing

Material: Chrome Steel GCr15

Structure: FE series Freewheelclutches transmit or support torque moment by friction contact

in one direction and permit idling in the opposite direction.

Application: indexing, backstop, overrunning

Sample: accept

Delivery time: 5-7 days after order confirmed.

Package: wooden box, carton or customized.

Payment terms: TT, L/C, D/A, D/P, Western Union, Paypal

Catalogue of fe one way clutch bearing for your choice

Designation d D W Tnom nmax Weight Item no.
[mm] [mm] [mm] [Nm] [rpm] [kg]
FE 412 Z 4 12 12 4 27,000 0.003 300393
FE 416 Z 8 16 12 16 19,200 0.006 300400
FE 420 Z 12 20 12 35 12,500 0.007 306041
FE 422 Z 14 22 12 53 10,100 0.008 300405
FE 423 Z 15 23 12 62 9,200 0.009 300411
FE 425 Z 17 25 12 72 8,100 0.011 300415
FE 427 Z 19 27 12 83 7,400 0.013 300422
FE 428 Z 20 28 12 93 7,500 0.013 300430
FE 430 Z 22 30 12 107 6,300 0.014 300435
FE 432 Z 24 32 12 117 5,900 0.016 300439
FE 433 Z 25 33 12 128 6,000 0.016 300445
FE 435 Z 27 35 12 143 5,100 0.017 300448
FE 437 Z 29 37 12 154 4,800 0.018 300455
FE 438 Z 30 38 12 166 4,900 0.019 300460
FE 442 Z 34 42 12 198 4,400 0.018 300463
FE 443 Z 35 43 12 207 4,300 0.022 300469
FE 448 Z 40 48 12 248 4,200 0.024 300478
FE 453 Z 45 53 12 293 3,400 0.022 300482
FE 455 Z 47 55 12 313 3,300 0.026 300487
FE 458 Z 50 58 12 344 3,100 0.029 300489
FE 459 Z 51 59 12 353 3,000 0.03 300494
FE 463 Z 55 63 12 393 2,900 0.032 300497
FE 468 Z 60 68 12 444 2,700 0.034 300501
FE 470 Z 62 70 12 465 2,600 0.035 300505
FE 473 Z 65 73 12 495 2,500 0.037 300508
FE 478 Z 70 78 12 548 2,600 0.039 300511
FE488Z 80 88 12 657 2,100 0.045 300514
FE 508 Z 100 108 12 889 1,700 0.055 300519
FE 528 Z 120 128 12 1,127 1,300 0.066 300522
FE 648 Z 240 248 12 2,673 800 0.131 300524

Detailed Images

Company Information

Changzhou Suma Precision Machinery Co., Ltd(Changzhou Tianniu Clutch Factory)is a manufacturer specialized in Producing Various cam clutch, one way bearing, one way clutch, backstop clutch, overrunning clutch and other bearings with high technology.

We are following "Best Quality, Best Price, Fast Delivery, Best Serves" to make all of our old and new customers satisfied.

Production flow

Certifications

Clients Visit

FAQ

Q: How do you pack the goods?

  • Total less than 25 KG : Each in white box + 19*18*9cm box + 29*28*19CM carton box
  • Total Weight over 100KG : Carton box + Wooden Box / Wooden Pallet

Q: Can i get the samples from you?

A: It is highly encouraged to ask for the samples for quality check.

Q: Can you promise to deliver the goods in time?

  • Small items: In stock.
  • Medium Items: 10-15 Days
  • Big items: 20-25 Days
