Specifications
Brand Name :
SUMA
Model Number :
AS
Place of Origin :
Jiangsu, China
MOQ :
2
Type :
SPRAG
Precision Rating :
P0
Seals Type :
Open
Thickness :
6-26mm
Inner diameter :
9-80mm
Outer diameter :
19-140mm
Torque capacity :
2.1-1063Nm
Weight :
0.01-1.14kg
Material :
GCr15
Overrunning speeds :
5000-600 min-1
Drag torque :
0.18-58 Ncm
Axial misalignment :
± S/2
Tolerance :
r6 (outer race)
Installation fit :
H7 housing
Structure :
Roller type freewheel
Description

Ratchet Wheel / One Way Clutch Ratchet

Features of One way clutch ratchet

SPECIFICATIONS

Product name

One way clutch ratchet

Material

GCr15

Thickness

P6

Inner diameter

6-80mm

Outer diameter

19-140mm

Torque capacity

2.1-1063Nm

Weight

0.01-1.14kg

Application

Industrial machines

Package

Wooden box, tube, pulley, etc

Payment terms

TT. L/C, D/A,D/P,Western Union

Delivery time

2-4 days for the sample, 7 days for big order

Performance Characteristic of one way clutch ratchet

Structure: This type star wheel one way ratchet wheel is a roller type freewheel non-bearing supported. Bearings are required to support axial and radial loads. Lubrication and sealing must also be provided by the installation. Nominal outside dimensions are the same as series 62...Ball bearings.
Installation: A typical arrangement is to install this type alongside a series 62 bearing within the same location tolerances. The inner race is keyed to the shaft (except 6 mm bore).
Tolerance: The outer race of the one way ratchet has a positive r6 tolerance to give a press fit in a H7 housing. The outer housing must be strong enough to not expand after assembly. This design can accept an axial misalignment of inner and outer race of ± S/2.

Detailed Images

SPRAG One Way Clutch Ratchet for Industrial MachinesSPRAG One Way Clutch Ratchet for Industrial MachinesSPRAG One Way Clutch Ratchet for Industrial MachinesSPRAG One Way Clutch Ratchet for Industrial MachinesSPRAG One Way Clutch Ratchet for Industrial Machines

Catalogue of full cylindrical roller bearing for your choice

Type Size Overrunning speeds Weight Drag torque
Star wheel dH7 TKN1) nimax2) namax3) Dr6 D5 L s e f TR
[mm] [Nm] [min-1] [min-1] [mm] [mm] [mm] [mm] [mm] [mm] [kg] [Ncm]
6 2.1 5000 7500 19 15.8 6 0.3 0.6 0.3 0.01 0.18
8 3.8 4300 6500 24 20 8 1.3 0.6 0.6 0.02 0.24
10 6.8 3500 5200 30 25.9 9 1.3 0.6 0.6 0.03 0.36
12 13 3200 4800 32 28 10 1.3 0.6 0.6 0.04 0.48
15 14 2800 4300 35 31 11 1.4 0.6 0.6 0.05 0.7
20 40 2200 3300 487 40 14 2.4 0.8 0.8 0.12 1.4
25 56 1900 2900 52 45.9 15 2.4 0.8 0.8 0.14 2.4
30 90 1600 2400 62 55 16 2.4 0.8 1 0.22 7.8
35 143 1300 2000 72 64 17 2.5 0.8 1 0.31 9
40 185 1200 1800 80 72 18 2.5 0.8 1 0.39 10
45 218 1000 1600 85 77 19 2.5 1.2 1 0.44 11
50 230 950 1500 90 82 20 2.5 1.2 1 0.49 13
55 308 800 1300 100 90 21 2.5 1.2 1 0.66 14
60 508 700 1100 110 100 22 2.5 1.2 1.5 0.81 26
80 1063 600 900 140 128 26 2.5 1.2 1.5 1.41 58

SPRAG One Way Clutch Ratchet for Industrial MachinesSPRAG One Way Clutch Ratchet for Industrial MachinesSPRAG One Way Clutch Ratchet for Industrial Machines

FAQ

Q: How do you pack the goods?

  • Total less than 25 KG : Each in white box + 19*18*9cm box + 29*28*19CM carton box
  • Total Weight over 100KG : Carton box + Wooden Box / Wooden Pallet

Q: Can i get the samples from you?

A: It is highly encouraged to ask for the samples for quality check.

Q: Can you promise to deliver the goods in time?

  • Small items: In stock.
  • Medium Items: 10-15 Days
  • Big items: 20-25 Days
