FGK25 Sprag One Way Bearing 25mm ID 42mm OD 70Nm Torque
FGK25 Sprag One Way Bearing 25mm ID 42mm OD 70Nm Torque
FGK25 Sprag One Way Bearing 25mm ID 42mm OD 70Nm Torque
FGK25 Sprag One Way Bearing 25mm ID 42mm OD 70Nm Torque
FGK25 Sprag One Way Bearing 25mm ID 42mm OD 70Nm Torque
FGK25 Sprag One Way Bearing 25mm ID 42mm OD 70Nm Torque
FGK25 Sprag One Way Bearing 25mm ID 42mm OD 70Nm Torque
FGK25 Sprag One Way Bearing 25mm ID 42mm OD 70Nm Torque
FGK25 Sprag One Way Bearing 25mm ID 42mm OD 70Nm Torque
FGK25 Sprag One Way Bearing 25mm ID 42mm OD 70Nm Torque
FGK25 Sprag One Way Bearing 25mm ID 42mm OD 70Nm Torque
FGK25 Sprag One Way Bearing 25mm ID 42mm OD 70Nm Torque
Specifications
Model Number :
FGK 25
Brand Name :
SUMA
Place of Origin :
Jiangsu, China
MOQ :
1
Precision Rating :
P6
Seals Type :
Open
Outer diameter :
42mm
Inner diameter :
25mm
Height :
48mm
Material :
Chrome steel GCr15
Torque :
70Nm
Bore diameter :
25mm
Torque capacity :
70Nm
Inner race speed :
530r/min
Outer race speed :
3800r/min
Dynamic load :
6300N
Static load :
3450N
Weight :
0.11kg
Type :
sprag
Description

FGK 25 Sprag Clutches Freewheels One Way Bearing FGK25

Product Description

Structure of fgk one way bearing :

Internal Freewheels FGK are sprag freewheels with bearing support in the dimensions of the

needle bearing series 59.

Freewheels FGK are used as:

Backstops

Overrunning Clutches

Indexing Freewheels

Specification

ModelFGK25
Materail
Gcr15
Bore diameter
25mm
Outer diameter
42mm
Height
48mm
Torque capacity
70Nm
Inner race overrun speed
530r/min
Outer race overrun speed3800r/min
Application Automobiles, motorcycles, power tools, textile machines,
Package carton package / Wooden package
Delivery time 5-7 days
Payment termsTT, L/C, D/P, D/A, Western Union, Paypal

Catalogue of fgk one way bearing for your choice

FGK25 Sprag One Way Bearing 25mm ID 42mm OD 70Nm Torque

SizeNominal Torque MNMax. speedLoad rating of bearing supportBore dDKLWeight
Inner ringOuter ring freewheels/overruns Dynamic C Static Cmmmmmmmmkg
freewheels/ overruns
Nmmin-1min-1Roller Ball Roller Ball
N NNN
FGK20505 5004 0005600440029002750203742230,09
FGK25705 3003 8006300530034503350254248230,11
FGK30955 0003 5007700550046003650304754230,13
FGK35200460032008200850052005700355563270,20
FGK40310420030008650830057505700406270300,30
FGK45370380025009200965063507200456876300,34
FGK504603400220096501000069507800507280300,36
Detailed Images

FGK25 Sprag One Way Bearing 25mm ID 42mm OD 70Nm Torque

Company Information

Changzhou Suma Precision Machinery Co., Ltd(Changzhou Tianniu Clutch Factory)is a manufacturer specialized in Producing Various cam clutch, one way bearing, one way clutch, backstop clutch, overrunning clutch and other bearings with high technology.

FGK25 Sprag One Way Bearing 25mm ID 42mm OD 70Nm Torque

We are following "Best Quality, Best Price, Fast Delivery, Best Serves" to make all of our old and new customers satisfied.

Production flow

FGK25 Sprag One Way Bearing 25mm ID 42mm OD 70Nm Torque

Certifications

FGK25 Sprag One Way Bearing 25mm ID 42mm OD 70Nm Torque

FAQ

Q: How do you pack the goods?

  • Total less than 25 KG : Each in white box + 19*18*9cm box + 29*28*19CM carton box
  • Total Weight over 100KG : Carton box + Wooden Box / Wooden Pallet

Q: Can i get the samples from you?

A: It is highly encouraged to ask for the samples for quality check.

Q: Can you promise to deliver the goods in time?

  • Small items: In stock.
  • Medium Items: 10-15 Days
  • Big items: 20-25 Days
