CSK17 One Way Bearing 17mm ID 40mm OD Sprag Type
CSK17 One Way Bearing 17mm ID 40mm OD Sprag Type
CSK17 One Way Bearing 17mm ID 40mm OD Sprag Type
CSK17 One Way Bearing 17mm ID 40mm OD Sprag Type
CSK17 One Way Bearing 17mm ID 40mm OD Sprag Type
CSK17 One Way Bearing 17mm ID 40mm OD Sprag Type
CSK17 One Way Bearing 17mm ID 40mm OD Sprag Type
CSK17 One Way Bearing 17mm ID 40mm OD Sprag Type
CSK17 One Way Bearing 17mm ID 40mm OD Sprag Type
CSK17 One Way Bearing 17mm ID 40mm OD Sprag Type
Specifications
Model Number :
CSK17 one way bearing
Brand Name :
SUMA
Place of Origin :
Jiangsu, China
MOQ :
5
Price :
$1.80-2
Precision Rating :
P0
Seals Type :
open
Type :
sprag, sprag type
Material :
Steel, GCr15
Weight :
0.09kgs
Torque capacity :
30Nm
Inner diameter :
17mm
Outer diameter :
40mm
Dynamic load :
7.9kN
Static load :
3.8kN
Max speed :
7350min-1
Bearing series :
6203
Drag torque :
1.1Ncm
Length :
12mm
Bearing loads :
7.9kN, 3.8kN
Description

Electric Bike Bearing CSK17 One Way Clutch CSK 17

Product Description

Features of sprag one -way clutch: One way bearing CSK2RS is a sparg type freewheel integrated into a 62series ball bearing( except size 8 and 40).

Packing details: bearing supported, delivered grease lubricated and protected against dust of more than 0.3mm.

Product name

CSK17 one way bearing

Inner diameter

17mm

Outer diameter

40mm

Material

GCr15

Torque capacity

30Nm

Weight

0.07kg

Package

Carton Box / Wooden box

Payment terms

TT. L/C, D/A,D/P,Western Union

Delivery time

2-4 days for the sample, 7 days for big order

Catalogue of csk17 one way bearing for your choice

Tips: All the CSK versions are equippede with " formchromed" sprags. This process increases several times the overrunning life time.

CSK17 One Way Bearing 17mm ID 40mm OD Sprag Type

Type

Size

Bearing series

Bearing loads

Weight

Drag torque

dynamic

static

CSK(KK)

d

TKN1)

N max

D

L

C

C0

TR

[mm]

[Nm]

[min-1]

[mm]

[mm]

[kN]

[kN]

[kg]

[Ncm]

8*

–

2.5

15000

22

9

3.28

0.86

0.015

0.5

12

6201

9.3

10000

32

10

6.1

2.77

0.04

0.7

15

6202

17

8400

35

11

7.4

3.42

0.06

0.9

17

6203

30

7350

40

12

7.9

3.8

0.07

1.1

20

6204

50

6000

47

14

9.4

4.46

0.11

1.3

25

6205

85

5200

52

15

10.7

5.46

0.14

2

30

6206

138

4200

62

16

11.7

6.45

0.21

4.4

35

6207

175

3600

72

17

12.6

7.28

0.3

5.8

40

–

325

3000

80

22

15.54

12.25

0.5

7

CSK..2RS

8**

2.5

15000

22

9

3.28

0.86

0.015

0.8

12

–

9.3

10000

32

14

6.1

2.77

0.05

3

15

17

8400

35

16

7.4

3.42

0.07

4

17

30

7350

40

17

7.9

3.8

0.09

5.6

20

50

6000

47

19

9.4

4.46

0.145

6

25

85

5200

52

20

10.7

5.46

0.175

6

30

138

4200

62

21

11.7

6.45

0.27

7.5

35

175

3600

72

22

12.6

7.28

0.4

8.2

40

–

325

3000

80

27

15.54

12.25

0.6

10

Detailed Images

CSK17 One Way Bearing 17mm ID 40mm OD Sprag TypeCSK17 One Way Bearing 17mm ID 40mm OD Sprag TypeCSK17 One Way Bearing 17mm ID 40mm OD Sprag TypeCSK17 One Way Bearing 17mm ID 40mm OD Sprag TypeCSK17 One Way Bearing 17mm ID 40mm OD Sprag Type

Production flow

CSK17 One Way Bearing 17mm ID 40mm OD Sprag Type

Company Information

CSK17 One Way Bearing 17mm ID 40mm OD Sprag Type

Changzhou Suma Precision Machinery Co., Ltd(Changzhou Tianniu Clutch Factory)is a manufacturer specialized in Producing Various cam clutch, one way bearing, one way clutch, backstop clutch, overrunning clutch and other bearings with high technology.

CSK17 One Way Bearing 17mm ID 40mm OD Sprag Type

We are following "Best Quality, Best Price, Fast Delivery, Best Serves" to make all of our old and new customers satisfied.

Certifications

CSK17 One Way Bearing 17mm ID 40mm OD Sprag Type

Clients Visit

CSK17 One Way Bearing 17mm ID 40mm OD Sprag Type

FAQ

Q: How do you pack the goods?

  • Small Items:

Each in small white box or Roll Pack or Tube pack - in 19x18x9CM carton box - 29*28*19CM carton box - Wooden box / Wooden pallet

  • Medium Items: 29*28*19cm carton box + Wooden box /Wooden pallet
  • Heavy Items: Wooden Box / Wooden Pallet

Q: Can i get the samples from you?

A: It is highly encouraged to ask for the samples for quality check.

Q: Can you promise to deliver the goods in time?

  • Small items: In stock.
  • Medium Items: 10-15 Days
  • Big items: 20-25 Days
