Description
CV213 110-213-000-012
Product Overview
The CV213 110-213-000-012 is a moving-coil velocity sensor designed specifically for low-frequency, high-temperature industrial vibration monitoring applications. The sensor's sensing element consists of a coil that moves around a permanent magnet, generating a voltage signal proportional to the vibration velocity.
As a self-powered sensor, the CV213 operates without an external power supply and can be connected directly to the monitoring system via a dedicated cable assembly, eliminating the need for an additional signal conditioner. Its rugged anodized aluminum housing and waterproof, sealed connectors enable long-term, stable operation in harsh industrial environments, including those with high humidity, corrosive conditions, and high temperatures.
Key Features
  • Frequency response down to 10 Hz
  • Voltage output signal
  • No need for additional signal conditioner
  • No power supply required
  • Wide transducer mounting orientation
  • Dust and moisture resistant: IP64 protection rating
  • Certified for use in potentially explosive atmospheres
  • Temperature range: CV213: −29 to 204°C (−20 to 400°F)
Product Specifications
Brand Name Other
Model CV213
Ordering Information 110-213-000-012
Catalog Velocity Transducers
Gross Weight/Shipping Weight 2.2 lbs / 35.2 oz / 1kg
Packing Size 16cm x 16 cm x 12 cm
Country of Origin China
HS Code 8537101190
Lead Time In Stock
Shipping Port Xiamen
Payment T/T
Sales Price $6700
Warranty 12 months
Lead Time 3-5 work days
Courier Partners DHL, UPS, TNT, FedEx and EMS
Product Selection and Pairing
Matching Cable Assembly ED120 Dedicated Cable Assembly
Cable Type K220 (2×0.5 mm² stranded conductors) or K225 (2×0.25 mm² stranded conductors), PTFE insulation
Operating Temperature −65°C to 204°C (−85°F to 400°F)
Connector MIL-C-5015 10SL-4SN (for use with CV213)
Nominal Length 15 m
Construction 2-wire, shielded
CV213 110-213-000-012
Case Study
A certain thermal power plant installed multiple CV213 sensors in the high, medium, and low-pressure cylinders and bearing housings of its steam turbines. The sensors operated continuously and stably at ambient temperatures as high as 200°C, effectively monitoring vibration changes during unit start-up, shutdown, and load variations, and providing reliable data support for the safe operation of the units.
Frequently Asked Questions
What precautions should be taken when using the device in particularly harsh environments?
In extremely harsh industrial environments, it is recommended to install a flexible metal conduit around the cable assembly to provide additional mechanical protection.
What is the CV213's protection rating?
The CV213 has an IP64 protection rating (in accordance with IEC 60529), providing protection against dust and splashing water.
How much does the sensor weigh?
The CV213 weighs approximately 0.4 kg.
What is the warranty period?
Standard industrial warranty: 12 months; with proper installation and no overloading, the product has a service life of 5-10 years.
